Evaluates: MAX16165/MAX16166
JEN2
JEN3
JEN3
JEN4
JEN4
JLOAD
JLOAD
-
JPULLUP
JLED
JLED
*
Default position
www.analog.com
Not Installed
EN
1-2*
Not Installed
1-2*
Not Installed
1-2*
3-4*
VLDOOUT_
5-6*
7-8*
1-2
3-4
OUT_
5-6
7-8
DONE 9-10
POK 11-12
1-2*
3-4*
OUT_
5-6*
7-8*
DONE 9-10*
POK 11-12*
MAX16165/MAX16166 Evaluation Kit
Sequencer only operation; DC-DC mode with feedback from
LDO is disabled
Connects OUT3 with EN of U4
Sequencer only operation; DC-DC mode with feedback from
LDO is disabled
Connects OUT4 with EN of U5
Sequencer only operation; DC-DC mode with feedback from
LDO is disabled
Connects VLDOOUT1 with RLOAD1
Connects VLDOOUT2 with RLOAD2
Connects VLDOOUT3 with RLOAD3
Connects VLDOOUT4 with RLOAD4
Connects OUT1 with PULLUP resistor
Connects OUT2 with PULLUP resistor
Connects OUT3 with PULLUP resistor
Connects OUT4 with PULLUP resistor
Connects DONE with PULLUP resistor
Connects POK with PULLUP resistor
Enables LED indicator for OUT1
Enables LED indicator for OUT2
Enables LED indicator for OUT3
Enables LED indicator for OUT4
Enables LED indicator for DONE
Enables LED indicator for POK
