Install Lever; Insert Interface Cylinder - Alarm Lock DL1200 Mounting And Installation Instructions Manual

LH
"arm"
Fig. 2d: The RH spring is installed at the factory; the LH spring is supplied.
2e. Pre-load the spring by placing the " anchor" end
over the "arm". See Fig. 2e below.
"arm"
"anchor"
Fig. 2e: Pre-load the spring (LH shown) before installing.
2f. Insert the pin through
the top of the new LH
spring.
2g. Insert the pin/spring
through the retractor arm
hole while simultaneously
inserting the "anchor" end
of the spring into the
small hole in the cylinder/
adapter. See Fig. 2g.
Pull the arm and hook its end onto the retractor arm.
Insert "anchor" end
into this hole.
Fig. 2g: Insert pin and spring; pull arm and clip on hook cam lever.
2h. Re-install the retaining ring
displayed in Fig. 2h.
Fig. 2i: Ready for LH operation.
4
RH
(factory installed)
"anchor" "anchor"
"anchor"
placed behind
"arm"
Fig. 2f: Insert pin into top of
spring.
Fig. 2h: Re-install retaining ring.
Finished configuration
shown at left (Fig. 2i).
Install the Lever
3. Install the lever with
proper
the lock/door hand used.
"arm"
Tighten the set screw us-
ing a 1/8" hex wrench
(see Fig. 3).
IMPORTANT! The top of
the set screw must be at
(or below) lever surface. If
not, check to ensure the
lever is fully pushed to-
ward the trim.
3a. Install the Adams Rite
Adams Rite
lines and instructions.
 If a new installation, the
face place must NOT be
installed at this time.
 If a retrofit installation,
remove the face plate.
Prepare the Door For
"Through-Bolting"
4. Place template (WI1459) as
shown.
the template on top of existing
cylinder hole and parallel to the
door edge.
4a. Drill completely through the door for through-bolting
the four mounting holes and battery cover access
bolt hole.
 IMPORTANT!--Drill
THROUGH the door, or the through-bolts will not
fit in the lock! THIS IS ESSENTIAL! Drill slowly
and STRAIGHT through the door.
 Reposition the template as often as needed until
it is placed correctly.
pin
Insert the Interface Cylinder
5. Loosen the set screw, then remove the outside cylin-
der (if present--See Fig. 5).
orientation for
Fig. 3: Tighten lever set screw
®
product as indicated by the
®
door prep guide-
Important: Place
the
Set screw
Fig. 5: Loosen set screw before removing the
old interface cylinder (if present)
with 1/8" hex wrench
Fig. 4: Template (WI1459)
through-bolt holes (circled)
holes STRAIGHT
Old interface
cylinder
