Alarm Lock Networx DL1325NW Mounting Installation Instructions

345 Bayview Avenue, Amityville, New York 11701
For Sales and Repairs 1-800-ALA-LOCK
For Technical Service 1-800-645-9440
or visit us at http://tech.napcosecurity.com/
(Note: Technical Service is for security professionals only)
Publicly traded on NASDAQ Symbol: NSSC

GENERAL DESCRIPTION

The DL1325NW, PDL1325NW, DL1350NW and PDL1350NW
are keypad programmable or wirelessly programmable
(through DL-Windows software) narrow stile entry trim for Ad-
®
ams Rite 1850, 1950, 4070, MS1850S, MS1950S, MS1950,
MS1850S-050 and MS1950-050 series deadbolts for narrow
stile aluminum doors*.
The DL13XXNW and PDL13XXNW will retract the existing Ad-
®
ams Rite deadbolt when an access code is entered (or a cre-
dential is presented) and the turnpiece is turned. All locks are
equipped with a mechanical metal key override. For program-
ming information, visit
tech.napcosecurity.com
tions for the PDL13XXNW (WI2258) and DL13XXNW
(WI2264).

MECHANICAL FEATURES

The overall enclosure housing is 15-5/16" inches high, 1-5/8"
inches deep and 1-¾" inches wide. The trim is through-bolted
to the stile of the door (using four #10 screws) and are secured
on the interior side of the door. Supported stile thickness is 1-
¾".
 DL13XXNW and PDL13XXNW models support 5000 us-
ers and includes 36,000-event audit trail and 500 event
schedule. Keypad or PC programmable
 Aluminum door retrofit outside trim for Adams Rite
1950, 4710, 4070, MS1850S and MS1950S Series locks
 All-metal, vandal-resistant 12-button keypad supports 3-6
digit PIN codes, and multilevel user hierarchy (master,
manager, supervisor and basic users)
 Keypad or PC programmable (see model information).
Quickly and easily add or delete users and enter
"passage mode", service codes, group lock-out & group-
enable
 PDL13XXNW series locks support proximity ID cards,
keyfobs and proximity tags with its integral proximity read-
er (high security applications can require use of both PIN
code plus proximity credential for access)
 Real time clock and PC programmable automatic lock/
unlock scheduling for 500 events
 Wide weatherproof operating range from -31ºF to 151ºF
(-35ºC to 66ºC)
 Provides 50,000 operations using 4AA batteries; includes
audible and visual low battery alert
 Non-handed; fully field-reversible
MOUNTING & INSTALLATION INSTRUCTIONS
© ALARM LOCK 2019
our Technical
and download programming instruc-
Networx
Narrow Stile Access Locks
 Mechanical key override; interchangeable cores support-
ed (Corbin/Russwin, Yale, Schlage, Medeco)
 Mortise Cylinder, 1-¼" supplied (supports 1-1/8", 1-¼",
1-3/8" and 1-½"
 Backsets 31/32",1-1/8" and 1-½"; stile thickness 1-¾"
MOUNTING AND INSTALLATION
For factory prepped doors, use dimensions shown. Di-
Library at
mensions are referenced from center of 1-¼" cylinder hole.
The Adams Rite lock determines the backset.
When mounting the new Adams Rite locks:
 Do not install the outside cylinder -- this trim replaces it;
 Do not install the faceplate (access to the cylinder set
screw in the lock is required during mounting and installa-
tion).
Mechanical Override Cylinder Cams
The DL13XXNW and PDL13XXNW trim requires the use of an
oval Alarm Lock cam (supplied with cylinder). For other manu-
facturers, please see the charts on the next page.
®
1850,
GENERAL DESCRIPTION .................................................... 1
MECHANICAL FEATURES ................................................... 1
MOUNTING AND INSTALLATION ........................................ 2
INSTALL CYLINDER ........................................................ 3
PREPARE DOOR FOR "THROUGH-BOLTING" ............ 3
INSTALL INTERFACE CYLINDER ............................ 4
CONNECT BATTERIES .............................................. 4
INSTALL LOCK ........................................................... 5
MECHANICAL KEY OVERRIDE ................................. 6
ALARM LOCK LIMITED WARRANTY ................................... 8
*Adams Rite Manufacturing Co., Pomona, CA. www.adamsrite.com. All products, product names and services
described in this manual are for identification purposes only and may be trademarks of their respective companies.
™

TABLE OF CONTENTS

WI2357LF 6/19
1
