345 Bayview Avenue, Amityville, New York 11701

For Sales and Repairs 1-800-ALA-LOCK

For Technical Service 1-800-645-9440

or visit us at

http://tech.napcosecurity.com/

(Note: Technical Service is for security professionals only)

Publicly traded on NASDAQ

Symbol: NSSC

GENERAL DESCRIPTION

The DL1200, DL1300 and PDL1300 are manually programma-

ble narrow stile entry trim for Adams Rite

deadlatch locks, and 1850, 1950, 4070, MS1850S and

MS1950S series deadbolts for narrow stile aluminum doors*.

The DL1200, DL1300 and PDL1300 will retract the existing Ad-

ams Rite

latch when an access code is entered (or a credential

is presented) and the lever is pressed down (or the turnpiece

turned). The trim is designed to operate with any Adams Rite

interior device such as a "pushpaddle" or lever. Because Ad-

ams Rite

trim exists on the inside, the "hold-back feature re-

mains operational for a continuous unlatched function (see Ad-

ams Rite

instructions).

code activates latched passage mode (device is unlocked but

the lever or turnpiece is engaged continuously) until another

passage mode function code is entered, re-locking the trim. All

locks are equipped with a mechanical metal key override. See

OI310, OI311 or OI312 for programming information.

MECHANICAL FEATURES

The overall enclosure housing is 14 3/8" inches high, 1 5/8"

inches deep and 1¾" inches wide. The trim is through-bolted to

the stile of the door (using four #10 screws) and are secured on

the interior side of the door. Supported stile thickness is 1¾".

 DL1200 Series supports 100 users, fingertip/keypad pro-

grammable

 DL1300 Series supports 2000 users and includes 40,000

event audit trail and 500 event schedule. Keypad or PC

programmable

 PDL1300 Series supports 2000 PIN or Proximity users and

includes 40,000-event audit trail and 500 event schedule.

Keypad or PC programmable

 Aluminum door retrofit outside trim for Adams Rite

1950, 4710, 4070, 4730, 4900, MS1850S and MS1950S

Series locks

 Familiar Trilogy

programming & electronics

 All-metal, vandal-resistant 12-button keypad supports 3-6

digit PIN codes (3-5 digits on the DL1200), and multilevel

user hierarchy (master, manager, supervisor and basic

users)

 Keypad or PC programmable (see model information).

Quickly and easily add or delete users and enter "passage

mode", service codes, group lock-out & group-enable

DL1200 - DL1300 - PDL1300

4710, 4730 and 4900

Entering a passage mode function

NARROW STILE ACCESS LOCKS

MOUNTING AND INSTALLATION

INSTRUCTIONS

 HID Proximity ID cards, keyfobs and proximity tags sup-

ported in PDL1300 series which features built-in Proximity

reader (High security applications can require use of both

PIN code plus Proximity ID card for access)

 Real time clock and PC programmable automatic lock/

unlock scheduling for 500 events (1300 Series models)

 Wide weatherproof operating range from -31 to 151ºF (-35

to 66C)

 Provides 100,000 operations using off-the-shelf long life

DL123A lithium batteries, and includes audible and visual

low battery alert

 Non-handed; fully field-reversible

 Mechanical key override; interchangeable cores supported

(Corbin/Russwin, Yale, Schlage, Medeco)

 Mortise Cylinder, 1¼" supplied (supports 1-1/8", 1¼", 1-

3/8" and 1½"

 Compact styling 14-3/8"H x 1-5/8"D x 1¾"W

 Backsets 31/32",1-1/8" and 1½"; stile thickness 1¾"

GENERAL DESCRIPTION ..................................... 1

MECHANICAL FEATURES .................................... 1

MOUNTING AND INSTALLATION ........................ 2

INSTALL CYLINDER ......................................... 3

1850,

VERIFY HAND ................................................... 3

INSTALL LEVER ................................................ 4

INSERT INTERFACE CYLINDER ............... 4

INSTALL LOCK ............................................. 5

INSTALL BATTERIES ................................... 6

TEST OPERATION ................................................. 7

NAPCO LIMITED WARRANTY.............................. 8

*Adams Rite Manufacturing Co., Pomona, CA. www.adamsrite.com. All products, product names and services

described in this manual are for identification purposes only and may be trademarks of their respective companies.

WI1458GLF 7/23

Table of Contents

Need help?

Do you have a question about the DL1200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Alarm Lock DL1200

Page 1: Table Of Contents
 Real time clock and PC programmable automatic lock/ MS1950S series deadbolts for narrow stile aluminum doors*. unlock scheduling for 500 events (1300 Series models) The DL1200, DL1300 and PDL1300 will retract the existing Ad-  Wide weatherproof operating range from -31 to 151ºF (-35 ®...
Page 2: Mounting And Installation
HW1331 1-½ HW1342 Cylinder Collars: The DL1200 and DL/PDL1300 can use a 1-⅛" & 1¼" mor- tise cylinder without the use of a collar (1¼" requires two plastic spacers, supplied). For cylinders longer than 1¼" a collar is required. Order collars from an Alarm Lock distributor.
Page 3: Install Cylinder
(factory installed) Note: The trim is manufactured to use a 1-1/8" or 1¼" Alarm Lock mortise cylinder with a HW-1302 cam. If the cylinder that will be used is longer than 1¼", a collar must be utilized. Please see the collar information on the previous page.
Page 4: Install Lever
2d. Pre-load the spring by placing the "anchor" end over the Install the Lever "arm". See Fig. 2d below. 3. Install the lever with proper orientation for the "anchor" lock/door hand used. "arm" placed behind "arm" Tighten the set screw us- ing a 1/8"...
Page 5 5a. Push in latch and hold latch in all the way. Push in latch during interface cylinder installation Fig. 5d: Tighten the interface cylinder set screw Interface cylinder 5e. Install the latch face plate. Fig. 5a: Push latch in and hold 5b.
Page 6: Install Lock
The difference between the right and the left "gap" distances must not exceed 1/32". Connect Batteries If face of the lock body is not parallel to the surface of Loosen the #8-32 Phillips pan head screw located on the door and the difference between the left and right the rear side of the base plate at the bottom of the lock "gap"...
Page 7: Test Lock Operation
5. While pressing the default access code on the lock key- Test Step 1 pad (press "1 2 3 4 5" on the DL1200 and press "1 2 3 4 5 6" on the DL/PDL1300), note the following: 2. Release lever. Insert key and turn key fully counter- ...
Page 8: Alarm Lock Limited Warranty
This warranty shall not apply to any equipment, or any In no event shall ALARM LOCK be liable for an amount part thereof, which has been repaired by others, improp- in excess of ALARM LOCK's original selling price of the...
Page 9: Programming Instructions
Symbol: NSSC © ALARM LOCK 2012 OI310B 12/12 CONGRATULATIONS! Your new DL1200 Alarm Lock Trilogy electronic digital lock is a manually ® programmable narrow stile entry trim for Adams Rite 4710, 4730 and 4900 deadlatch locks, and 1850, 1950, 4070, MS1850S and MS1950S series deadbolts for narrow stile aluminum doors*.
Page 10: Wiring
Wiring Wiring: See the Installation Instructions for more information. Batteries: Use only two '123' Type Lithium batteries (Duracell P/N CR17345). Quick Start First Time Start Up 1. Unpack the lock from its factory packaging. 2. Connect the battery pack. 3. Listen for 3 beeps. The lock is now ready to accept programming. Note: Failure to follow this exact proce- dure can result in erratic lock behavior.
Page 11: Testing Codes
KEYPAD ANTI-TAMPER LOCKOUT - If 3 invalid User Access Codes are entered in succession, the lock will turn off for approximately 30 seconds to prevent tampering. The DL1200 will emit 2 beeps with a Red LED flash warning at the end of the anti-tamper period.
Page 12: Manager & User Location Worksheet
The DL1200 lock provides three "security levels": Master (can perform ALL functions), Manager (can perform SOME program- ming functions plus entry), and Basic User (entry only). In total, there are 104 "locations" inside the DL1200 lock: one Master Code, 10 Manager and 90 User Access Codes, and three "one-time entry" Service Codes. Where the Access Code is located will determine its security level.
Page 13: Manager & User Location Example
User Access Codes allow access only; Manager Codes allow more: Manager Codes have the ability to program and delete User Access Codes within that Manager's Bank (column). The DL1200 lock can hold up to 10 Manager Codes, one for each Bank (locations (00), (10), (20), (30), (40), (50), (60), (70), (80), (90)), and are all found at the top row of the grid be- low.
Page 14: Programming Worksheet: Functions
Programming Worksheet: Functions Directions: The Factory Master Code (1-2-3-4-5) must first be reprogrammed as a new Master Code before any other programming can take place. All new Access Codes must have the same number of digits as the new Master Code. Choose new Access Codes and write them in spaces provided (in pencil) before programming the lock.
Page 15: Programming Functions
Once the number of digits is selected, it cannot be changed unless all programming is erased and the Factory Default settings are re-loaded (power must be removed and re-applied as per the "Erase All Programming" procedure found on page 11. Required only if DL1200 is locked.
Page 16: Disable/Enable All
5. To signify the end of the Code Location function, the lock will flash both the GREEN and RED LEDs and will emit a low tone. If no free address is found, then the lock will emit a programming error tone sequence. No LED flashes/sounder beeps represent the number zero. Required only if DL1200 is locked.
Page 17: Add/Delete Service Codes
Bank (column), and all following Banks until another Manager appears. User Access Codes in Banks outside of that Manager's Bank cannot be programmed. Disable Groups __ __ __ __ __ ; 211 ; Master Code** Enable Groups __ __ __ __ __ ; 210 ; Master Code** Required only if DL1200 is locked.
Page 18: Disable/Enable Users In Bank
When a key is pressed, a beep will sound and a Red LED will flash. Other indications are: ▪ Access Granted: 1 beep and a Green LED flash. (When Pass Time ends, the DL1200 locks with a beep and a Red LED flash).
Page 19: Battery Replacement
With the the lock is now ready for use. If you test the DL1200 and supplied 5/64" Allen wrench, loosen the battery cover find the lock programming is lost, you may erase all pro- screw only until the battery cover is able to slide off.
Page 20: Limited Warranty
ALARM LOCK will, In no event shall ALARM LOCK be liable for an within said period, at its option, repair or replace any amount in excess of ALARM LOCK's original selling...
