BCM91250A
LED
S
Figure 7
shows the positions of the LEDs numerically. Compare
each LED in
Board ID
Color
D1
Green
D2
Green
D3
Green
D4
Green
D5
Green
D6
Green
D7
Green
D8
Green
Page
14
LEDs
Table
4.
Table 4: LED Descriptions
Description
PHY 0 Slave indicator
PHY 0 Receive indicator
PHY 0 Transmit indicator
PHY 0 Full Duplex indicator
PHY 0 Link 1 indicator
PHY 0 Link 2 indicator
PHY 1 Slave indicator
PHY 1 Receive indicator
B roadc om C or por ati on
Figure 7
Figure 7: LED Callouts
User Manual
number callouts with a description of
Document
91250A-UM100-R
05/18/04
