Board ID Color
D9 Green
D10 Green
D11 Green
D12 Green
D19 Green
D20 Green
D28 Green
D29 Green
D30 Green
D31 Green
D32 Green
D33 Green
D34 Red
D35 Red
Document 91250A-UM100-R
Table 4: LED Descriptions
Description
PHY 1 Transmit indicator
PHY 1 Full Duplex indicator
PHY 1 Link 1 indicator
PHY 1 Link 2 indicator
IDE HDD active indicator
Debug LED
5V Power good indicator
3.3V Power good indicator
2.5V Power good indicator
1.25V Power good indicator
1.2V Power good indicator
1.2V BCM1250 Core Power good indicator
2.5V Fuse blown indicator
3.3V Fuse blown indicator
