BCM91250A
ROM E
MULATOR
Note: The table layout reflects the physical location of the pins on the connector. Also all I/O
signals are 3.3 V outputs that are tolerant of 5V inputs.
Odd Pin Name
GND
P3300 (3.3 V PWR)
AD18
AD17
AD14
AD13
AD8
AD9
AD11
OE_L
AD10
ROMEMUCS_L
AD31
AD30
AD29
AD28
AD27
Page 12 Connectors
P
INOUT

Table 3: ROM Emulator Pinout

Odd Pin Even Pin
Number Number
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20
21 22
23 24
25 26
27 28
29 30
31 32
33 34
B roadc om C or por ati on
Even Pin Name
AD20
AD19
AD16
AD15
AD12
AD7
AD6
AD5
AD4
AD3
AD2
AD1
AD0
AD24
AD25
AD26
GND
