4.5.1. Conducted RF Output Power

Table 25: Conducted RF Output Power at 2.4 GHz
Description
802.11b
802.11b
802.11g
802.11g
802.11n (HT20)
802.11n (HT20)
Table 26: Conducted RF Output Power at 5 GHz
Description
802.11a
802.11a
802.11n, HT20
802.11n, HT20
802.11n, HT40
802.11n, HT40
802.11ac, VHT20
802.11ac, VHT20
802.11ac, VHT40
802.11ac, VHT40
802.11ac, VHT80
802.11ac, VHT80
FC80A_Hardware_Design
Rate
1 Mbps
11 Mbps
6 Mbps
54 Mbps
MCS0
MCS7
Rate
6 Mbps
54 Mbps
MCS0
MCS7
MCS0
MCS7
MCS0
MCS8
MCS0
MCS9
MCS0
MCS9
Wi-Fi&Bluetooth Module Series
Typ. Unit
18± 2.5 dBm
18 ± 2.5 dBm
18± 2.5 dBm
16.5 ± 2.5 dBm
18 ± 2.5 dBm
15.5 ± 2.5 dBm
Typ. Unit
14± 2.5 dBm
12± 2.5 dBm
14± 2.5 dBm
12± 2.5 dBm
14± 2.5 dBm
11± 2.5 dBm
14± 2.5 dBm
11± 2.5 dBm
14± 2.5 dBm
10± 2.5 dBm
14± 2.5 dBm
10± 2.5 dBm
