Table 31: Recommended Thermal Profile Parameters
Factor
Soak Zone
Max slope
Soak time (between A and B: 150 ° C and 200 ° C)
Reflow Zone
Max slope
Reflow time (D: over 217 ° C)
Max temperature
Cooling down slope
Reflow Cycle
Max reflow cycle
NOTE
1. During manufacturing and soldering, or any other processes that may contact the module directly,
NEVER wipe the module's shielding can with organic solvents, such as acetone, ethyl alcohol,
isopropyl alcohol, trichloroethylene, etc. Otherwise, the shielding can may become rusted.
2. The shielding can for the module is made of Cupro-Nickel base material. It is tested that after 12
hours' Neutral Salt Spray test, the laser engraved label information on the shielding can is still clearly
identifiable and the QR code is still readable, although white rust may be found.
3. If a conformal coating is necessary for the module, do NOT use any coating material that may
chemically react with the PCB or shielding cover, and prevent the coating material from flowing into
the module.
FC80A_Hardware_Design
Wi-Fi&Bluetooth Module Series
Recommendation
1–3 ° C/s
70–120 s
2–3 ° C/s
40–70 s
235 ° C to 246 ° C
-1.5 to -3 ° C/s
1
38 / 43
