4.6. Bluetooth Performance

The following table shows the Bluetooth transmitting and receiving performance of FC80A.
Table 29: Bluetooth Transmitting and Receiving Performance
Frequency
BR
EDR (π/4-DQPSK)
EDR (8-DPSK)
BLE (1M)

4.7. ESD Protection

If the static electricity generated by various ways discharges to the module, the module maybe damaged
to a certain extent. Thus, please take proper ESD countermeasures and handling methods. For example,
wearing anti-static gloves during the development, production, assembly and testing of the module;
adding ESD protective components to the ESD sensitive interfaces and points in the product design.
The following table shows the module's electrostatic discharge characteristics:
Table 30: Electrostatic Discharge Characteristics (25 º C, 45 % Relative Humidity)
Tested Interfaces
VBAT
GND
ANT_WIFI0
ANT_WIFI1
FC80A_Hardware_Design
Transmit power
12
0
0
7.5
Contact Discharge
± 8
± 8
± 8
± 8
Receive sensitivity
-89
-93
-87
-96
Air Discharge
± 12
± 12
± 12
± 12
Wi-Fi&Bluetooth Module Series
Unit
dBm
dBm
dBm
dBm
Unit
kV
kV
kV
kV
