NOTE
Keep all RESERVED pins open.
3.2. Pin Description
The following tables show the pin description of FC80A.
Table 3: I/O Parameters Definition
Type
AI
AO
AIO
DI
DO
DIO
PI
PO
Table 4: Pin Description
Power Supply
Pin Name
VBAT
VDDIO
GND
WLAN Application Interface
FC80A_Hardware_Design
Description
Analog Input
Analog Input
Analog Input/Output
Digital Input
Digital Output
Digital Input/Output
Power Input
Power Output
Pin No.
I/O
Description
Power supply for the
36
PI
module
Power supply for
34
PI
module's I/O pins
1, 3–8, 10–11, 23, 32, 39, 47
Wi-Fi&Bluetooth Module Series
Comment
It must be provided with sufficient
current up to 1.2 A.
VDDIO support two voltage domains
1.8 V or 3.3 V.
14 / 43
