EVAL-AD5338RDBZ User Guide

EVALUATION BOARD HARDWARE

MOTHERBOARD POWER SUPPLIES

The EVAL-MBnanoDAC-SDZ
dual power supplies.
The EVAL-AD5338RDBZ evaluation board can be powered either
from the SDP-B port or externally by the J5 and J6 connectors,
as described in Table 1.
Both AGND and DGND inputs are provided on the board. The
AGND and DGND planes are connected at one location on the
EVAL-MBnanoDAC-SDZ. It is recommended that AGND and
DGND not be connected elsewhere in the system to avoid ground
loop problems.
All supplies are decoupled to ground with 10 µF tantalum and
0.1 µF ceramic capacitors.
Table 1. Power Supply Connectors
Connector No. Label
J5, Pin 1 (J5-1) VDD
J5, Pin 2 (J5-2) AGND
J5, Pin 3 (J5-3) VSS
J6, Pin 1 (J6-1) VLOGIC
J6, Pin 2 (J6-2) DGND
Table 4. Link Functions
Link No. Function
REF1, REF2, REF3, REF4 These links select the reference source.
Position EXT selects an off-board voltage reference via the appropriate EXT_REF_x connector.
Position VDD selects V
Position 4.096V selects the on-board 4.096 V reference as the reference source.
Position 2.5V selects the on-board 2.5 V reference as the reference source.
Position 5V selects the on-board 5 V reference as the reference source.
LK5 This link selects the positive DAC analog voltage source.
Position A selects the internal voltage source from the
Position B selects the internal voltage source 3.3 V from the
Position C selects an external supply voltage, V
LK6 This link selects the VLOGIC voltage source.
Position 3.3V selects the digital voltage source from the
Position VLOGIC selects an external digital supply voltage, V
LK7 This link selects the negative DAC analog voltage source.
Position A selects V
Position B selects AGND.
motherboard supports single and
Voltage
Analog positive power supply, V
Single and dual supply 5.5 V.
Analog ground.
Analog negative power supply, V
Dual supply −5.5 V.
Digital supply from 1.8 V to V
Digital ground.
as the reference source.
DD
.
SS

MOTHERBOARD LINK OPTIONS

A number of link options are incorporated in the
MBnanoDAC-SDZ
conditions before using the board. Table 2 describes the positions
of the links to control the evaluation board via the
using a PC and external power supplies. The functions of these
link options are described in detail in Table 4. The positions listed
in Table 2 and Table 4 match the evaluation board imprints (see
Figure 12).
Table 2. Link Options Setup for
Link No.
REF1
REF2
REF3
REF4
LK5
LK6
.
DD
LK7

DAUGHTER BOARD LINK OPTIONS

.
SS
The EVAL-AD5338R
links set the least significant bits (LSBs) of the I
.
DD
the DACs. Table 4 describes the function of these links. For proper
device operation, position LK1 and LK2 to B.
Table 3. Link Options for Daughter Board
Link No.
LK1
LK2
SDP-B
ADP121
.
DD
SDP-B
LOGIC
Rev. 0 | Page 3 of 13
and must be set for the required operating
SDP-B
Position
2.5V
EXT
EXT
EXT
C
3.3V
B
daughter board has two link options. This
Pin Option
SCLK B (low, default), A (high)
SDIN B (low, default), A (high)
board.
on the motherboard.
board, 3.3 V.
.
UG-979
EVAL-
SDP-B board
Control
2 C addresses of
