Getting Started Guide

PROGRAMS INSTALLED

The software described in this section has now been copied or
installed.
CM3WSD.exe
The folder \ADuCMxxxV1.3\Software Tools\CM3WSD
provides an executable called CM3WSD.exe. This software
accepts a hex file and allows it to be downloaded via the USB
interface to the ADuCM360
You may want to add a shortcut link for this executable to your
desktop.
elves.exe
The \ADuCMxxxV1.3\Software Tools\Elves folder contains
the elves.exe files. These files are useful tools that accompany
the software function libraries in
\ADuCMxxxV1.3\Code\ADuCM360\common. Again, no
installation is required here, but you may want to add a shortcut
link for this executable to your desktop.
Driver
The J-Link OB emulator requires a driver, which is installed
automatically when the Segger J-Link Software is selected (see
Step 3 of the Software Installation Instructions section). At this
point, check that the driver is installed correctly.
Plug in the emulator and check the device manager (see
Figure 7).
Check that it appears in the Windows Device Manager in both
the communications port and the USB controllers lists.
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
device on your evaluation board.
The J-Link OB emulator drivers JLinkCDCInstaller_V1.2b.exe
can be installed from the ADuCMxxxV1.3\Segger folder, if
J-Link does not appear in the device manager as shown in
Figure 7.
Note that the drivers for J-Link Lite and interface boards
previously shipped in the
available online.
Rev. A | Page 5 of 16
ADuCM360/ADuCM361
Figure 7. Device Manager
ADuCM360 development system are
