INSTALLING AND CONNECTING
System connections
■
430/440 MHz
band antenna
(purchase separately)
to AH-106*/107*
Duplexer
(User
supplied)
Coaxial cables
(User supplied)
*Not available in European
countries as of May 2014.
ID-RP2C
ID-RP4000V
ID-RP2L*
(Assist 1)
to AH-106*/107*
[A]
[B]
Control cable
(supplied w/ID-RP4000V)
AC outlet
5 5
ID-RP2L*
(Assist 2)
[A]
[B]
OPC-1380
(supplied w/ID-RP2C)
OPC-1309
(supplied w/ID-RP4000V)
External DC power
supply 13.8 V
Red
+
AC power cable
Black
_
