DIGITAL VOICE REPEATER id-rp4000v S-14309XZ-C1 Dec. 2006...
Page 2
8. READ the instructions of test equipment thoroughly before connecting equipment to the transceiver. Icom, Icom Inc. and logo are registered trademarks of Icom Incorporated (Japan) in the United States, the United Kingdom, Germany, France, Spain, Russia and/or other countries.
TABLE OF CONTENTS SECTION SPECIFICATIONS SECTION INSIDE VIEWS SECTION DISASSEMBLY INSTRUCTIONS SECTION PARTS LIST SECTION MECHANICAL PARTS SECTION SEMICONDUCTOR INFORMATION SECTION BOARD LAYOUTS SECTION BLOCK DIAGRAM SECTION VOLTAGE DIAGRAM...
SECTION 1 SPECIFICATIONS ¤ GENERAL • Operating frequency range : Transmit 440–450 MHz Receive 440–450 MHz • Type of emission : F1D* (GMSK) *F7W for system operation • Transfer rate : 4.8 kbps • Frequency resolutions : 5, 6.25 kHz : ±0.8 kHz (based on 25˚C) •...
SECTION 2 INSIDE VIEWS REAR UNIT REAR UNIT REAR UNIT CHASSIS UNIT CHASSIS UNIT RX UNIT CHASSIS UNIT CHASSIS UNIT TX UNIT FRONT UNIT FRONT UNIT FRONT UNIT 2 - 1...
Page 7
APC amplifier* (IC1250: TA75S01F) Fan drive circuit Fan drive circuit Fan drive circuit Q1250: 2SB798 Q1251: 2SC4081 D1750: MA8082 Power switch circuit Power switch circuit Power amplifier (IC1162: RA18H1213G1) 1st VCO circuit TX mixer* (IC960: µPC8163TB-E3) TX RF amplifier (IC1021: µPC1678G) 2nd VCO circuit Quadrature modulator* (IC890: RF2485)
Page 8
SECTION 3 DISASSEMBLY INSTRUCTION • REMOVING THE COVER • REMOVING THE MAIN-T/R UNIT 1 Unscrew 12 screws A, and remove the cover B. 1 Unsolder 2 points A. (MAIN-T unit only) 2 Disconnect 2 cables C, and disconnect 2 cables D. 2 Unsolder 3 points B, and remove the ANT plate C.
