3 Software version
4 Electronics version
5 CRC checksum
6 Parameter display time
RS-485 - communica-
7
tion rate
9 RS-485 – parity check
RS-485 – number of
10
stop bits
Calculation of total en-
11
ergy consumption
LE-01MR v.2 – User manual v.1.0.0
0x1004 4100 R
0x1005 4101 R
0x1006 4102 R
0x100B 4107 R/W
0x100C 4108 R/W
0x100D 4109 R/W
0x100E 4110 R/W
0x100F 4111 R/W
1
Values indicate the version of the
1
meter and control software.
1
Time encoded in seconds. Setting
range 0 - 99 seconds, a value of 0
1
means that the automatic switch-
ing of the parameter view stops.
The communication rate is en-
coded in numerical form, according
to the following table:
Value Bitrate
1
6 9600 bps
7 19200 bps
8 38400 bps
9 115200 bps
Settings
Value
None
0
1
Odd
1
Even
2
Value Settings
1 1 1 – stop bit
2 2 – stop bits
The total energy is equal to:
Value Settings
1
Energy consumed (im-
1
port)
