domestic and industrial automation
Preview of the meter settings
By pressing the button on the front panel of the meter for three seconds, a menu will be displayed that
allows you to read the current meter settings. In order to switch the view to the next parameter, short
press the button on the meter panel.
No. Feature
1 Setup
2 Number of the meter
3 Meter address in the RS-485 net-
work
4 Baud rate
5 Parity
6 Number of stop bits
7 Parameter display time
8 Calculation of total energy con-
sumption
LE-01MR v.2 – User manual v.1.0.0
Value
000000000000
1 (default) – 247
6 – 9600 bps (default)
7 – 19200 bps
8 – 38400 bps
9 – 57600 bps
10 – 76800 bps
11 – 115200 bps
0 – None (default)
1 – Odd
2 – Even
Stop 1 – 1 (default)
Stop 2 – 2
Lcd xx, where xx is the time after which the meter view will
automatically switch to display the next parameter. A value of
0 stops automatic switching.
A parameter that shows how the total energy consumption
reading is obtained:
Value
Operation
1
Total energy = Import (energy imported)
2
Total energy = Export (energy exported)
3
Total energy = Import + Export
4
Total energy = Import - Export
10
