F&F LE-03MW CT Manual

Electric energy meter, 3-phase, 4-tariff, 2-way
Hide thumbs Also See for LE-03MW CT:

Advertisement

Quick Links

LE-03MW CT
Electric energy meter,
3-phase, 4-tariff, 2-way
Do not dispose of this device in the trash along with other waste!
According to the Law on Waste, electro coming from households free of charge and can
give any amount to up to that end point of collec� on, as well as to store the occasion of
the purchase of new equipment (in accordance with the principle of old-for-new, regard-
less of brand). Electro thrown in the trash or abandoned in nature, pose a threat to the
environment and human health.
Purpose
The LE-03MW CT is a static, (electronic), 2-way calibrated electri-
city meter of three-phase or three-phase designed for measure-
ment in a semidirect system.
A built-in real-time clock allows energy consumption to be me-
asured by different tariff zones. Equipped with communication
interfaces: RS-485 with Modbus RTU protocol and an optical
port compliant with EN62056 (IEC1107) allows remote reading
and configuration of the meter.
Configuration of the meter is done through the communication
port according to the software features of the Modbus RTU.
F&F Filipowski L.P.
Konstantynowska 79/81, 95-200 Pabianice, POLAND
phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71
www.fif.com.pl; e-mail: biuro@fif.com.pl
- 1 -

Advertisement

loading
Need help?

Need help?

Do you have a question about the LE-03MW CT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for F&F LE-03MW CT

  • Page 1 Electro thrown in the trash or abandoned in nature, pose a threat to the environment and human health. Purpose The LE-03MW CT is a static, (electronic), 2-way calibrated electri- city meter of three-phase or three-phase designed for measure- ment in a semidirect system.
  • Page 2 Operation and programming manual Detailed PDF instructions can be downloaded from the website: www.fif.com.pl from the product subpage. Functions » 3-phase, 2-way energy meter; » Semidirect measurement (direct measurement up to 6 A); » Energy measurement in 4 tariff zones; »...
  • Page 3: Measured Values

    » Optical communication port in accordance with EN62056 (IEC1107); » Pulse output SO with programmable number of pulses per kWh; » Multifunction LCD display. Measured values Consumed and supplied active energy AE+/AE- [kWh] Consumed and supplied reactive energy RE+/RE- [kvarh] Phase voltages U1, U2, U3 [V] Phase currents...
  • Page 4 The position of the ���� button is shown in the diagram on page 7. Energy consumption indications The maximum indicated value of electricity consumption de- pends on the selected value of the current transformer. Value Energy consumption reading 99999.999 kWh 30/5 99999.999 kWh 40/5...
  • Page 5: Pulse Output

    Value Energy consumption reading 4000/5 99999999 kWh 5000/5 99999999 kWh 6000/5 99999999 kWh 7500/5 99999999 kWh When the reading field is overflowing, the meter starts counting energy from the value of 0 kWh. Pulse output The indicator has a SO+/SO- pulse output. This allows you to connect a pulse meter-reading pulses generated by the meter.
  • Page 6: Service Program

    The meter has sealable input and output terminal covers to pre- vent any attempts to bypass the meter. Service program Software is available for configuring the meter via the RS-485 interface at www.fif.com.pl (on the subpage of the LE-03MW CT meter). - 6 -...
  • Page 7: Programming Button

    Meter number The meter is marked with individual serial number allowing its unambiguous identification. The marking is laser engraved and cannot be removed). Programming button The ���� button is located under the lower terminal cover of the meter. - 7 -...
  • Page 8 Mounting 1. Disconnect the power supply. 2. The indicator mounted on a rail in the distribution box. 3. Using a screwdriver, remove the screws and remove the front shield meter terminals. 4. Connect the voltage-controlled phase, following the indica- tions to terminals 1 (L1), 2 (L2), 3 (L3). 5.
  • Page 9: Wiring Diagram

    Wiring diagram 1 L1 phase – voltage measurement and power supply 2 L2 phase – voltage measurement and power supply 3 L3 phase – voltage measurement and power supply 4 N-wire – voltage measurement and power supply 5 current transformer – L3 phase, S2 terminal 6 current transformer –...
  • Page 10 7 current transformer – L2 phase, S2 terminal 8 current transformer – L2 phase, S1 terminal 9 current transformer – L1 phase, S2 terminal 10 current transformer – L1 phase, S1 terminal 20 RS-485 output (B) 21 RS-485 output (A) 23 pulse output (+) 24 pulse output (–) Technical data...
  • Page 11 counter reading range 0÷999999.99 kWh meter constant [kWh] 12000 pulses/kWh meter constant [kvarh] 12000 pulses/kvarh reading indication 2× red LED communication port RS-485 communication protocole Modbus RTU baud rate 1200, 2400, 4800, 9600 bps parity EVEN parity bits pulse outputs pulse outputs quantity type open collector...
  • Page 12: Warranty

    Dimensions Warranty F&F products are covered by a 24-month warranty from the date of purchase. The warranty is only valid with proof of purchase. Contact your dealer or contact us directly. CE declaration F&F Filipowski L.P. declares that the device is in conformity with the essential requirements of the Low Voltage Directive (LVD) 2014/35/EU and the Electromagnetic Compatibility (EMC) Directive 2014/30/UE.
  • Page 13 General work safety conditions » Please read the instructions carefully before installation. » The device should be installed and operated by qualified per- sonnel who are familiar with its design, operation, and asso- ciated risks. » Do not install a meter that is damaged or incomplete. »...
