- Page 1 Exchange movements in a double-sided round Profiline clock 1. remove the modules (ring with glass and dial) from housing. Module with hinge: Module without hinge: Remove 4 screws from inside of the clock © MOBATIME 1 / 4 TE-801323.00...
- Page 2 4. then loosen the screws on bottom side of the ring. 5. try to spread the ring, until the movement and with the complete dial can be removed to the top. The ring is quite strong, so it needs some strength to spread it. © MOBATIME 2 / 4 TE-801323.00...
- Page 3 12. Now you have to check again the 12:00 position: remove PoE and connect it again. When it is ok now, you can mount the dial back to ring. Be carefully that the 12:00 position of the dial is really exactly on top © MOBATIME 3 / 4 TE-801323.00...
- Page 4 14. Push the ring together and fix it so it is completely closed 15. Repeat steps 2 to 12 with the second module 16. Mount both modules back to the housing body 17. Test the clock with the time signal © MOBATIME 4 / 4 TE-801323.00...
