INSTRUCTION MANUAL
State-of-the-art technology digital clock
DC series
© MOBATIME
BE-800693.16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC Series and is the answer not in the manual?

Questions and answers

Related Manuals for Mobatime DC Series

Summary of Contents for Mobatime DC Series

  • Page 1 INSTRUCTION MANUAL State-of-the-art technology digital clock DC series © MOBATIME BE-800693.16...
  • Page 2 It is prohibited to reproduce, to store in a computer system or to transfer this publication in a way or another, even part of it. The copyright remains with all the rights with BÜRK MOBATIME GmbH, D-78026 VS-Schwenningen and MOSER-BAER AG – CH 3454 Sumiswald / SWITZERLAND.

  • Page 3: Table Of Contents

    Control of the stopwatch using IR remote control ................... 28 The stopwatch menu ..........................28 Setting of initial time for counting down....................29 Switching contact ........................... 29 Stopwatch menu table ..........................30 Local time calculation ..........................32 © MOBATIME 3 / 52 800693.16...
  • Page 4 Synchronization and time setting – P5 mode 1 and 3 ..............35 10.3.2 Synchronization only – P5 mode 2 and 4 ..................35 10.4 Slave clock controlled by MOBATIME serial code, MOBALine, or IRIG-B ..........35 10.5 Slave clock controlled by IF482 over RS232 or RS485 ................. 35 10.6 Slave clock controlled by supervised RS485 ..................

  • Page 5: Description

    • autonomous, quartz controlled time base with the possibility of synchronization using the following: DCF 77 radio signal, 24 V minute impulses, the MOBATIME serial code, MOBALine, RS 232, RS 485, IRIG-B or GPS •...
  • Page 6 IR controller for clock set up and stopwatch control On request • internal relay – relay can switch for specified duration, when the stopwatch in the countdown mode reach the zero. • protection degree IP 54 © MOBATIME 6 / 52 800693.16...

  • Page 7: Assembly

    Insert Allen key into the opening on the bottom side of the clock. Turn the key softly in anticlockwise direction. The frame catch will snap in. • Replace the blind cap on the opening. • To loosen the frame catch, use the reverse procedure (turn clockwise). © MOBATIME 7 / 52 800693.16...

  • Page 8: Double-Sided Clock

    (after placing the parts the plate shall not be seen). • Remove the blind cap from the opening on the both lower sides of clock. © MOBATIME 8 / 52 800693.16...

  • Page 9: Dismantling Of The Clock Rear Cover

    To loosen the frame catch, use the reverse procedure (turn clockwise). • Note: during the disassembly first withdraw the clock, and suspend the suspension on the upper groove at the pipe insert. Dismantling of the clock rear cover © MOBATIME 9 / 52 800693.16...

  • Page 10: Assembly Diagram

    Assembly diagram Connecting terminal block Note: For PoE version is Ethernet cable plugged directly into the connector on the control board (this version is without terminal block) © MOBATIME 10 / 52 800693.16...

  • Page 11: Control Pcb

    Control PCB © MOBATIME 11 / 52 800693.16...

  • Page 12: Function Of The Plug Connectors

    Function of the plug connectors  LINES, DC/DCF OUT – JP1 time signal inputs: The DCF/GPS receiver, polarized impulse line, MOBALine, MOBATIME serial code, IRIG-B, power supply output: DC OUT 11–19 V or passive DCF current loop output  TEMP – JP2 connection of the temperature sensor(s) ...

  • Page 13: Connection Of The Cable Ends

    Connection of the cable ends Installation LINES / DC OUT wire connection TEMP wire connection – 1 or 2 thermometers CTRL wire connection RS-232 wire connection RS-485 wire connection RELAY connection © MOBATIME 13 / 52 800693.16...

  • Page 14: Control Of The Clock Using Keyboard Or Pushbuttons

    Function of the pushbuttons in the “Time and date setting“ mode. PB1S advancement to another item to be set up PB2S increase of the item to be set up by 1 PB2L continuous increase of the current item © MOBATIME 14 / 52 800693.16...

  • Page 15: Menu For The Setting Of The Clock Parameters

    The setting unit is 1/100 second. Setting range -9.99 to +9.99. Push PB1L to save the setting and return to menu item P4. Push together PB1L and PB2L to return to P4 without storage of the data © MOBATIME 15 / 52 800693.16...

  • Page 16: Submenu For Network Services Configuration

    Switch to the next octet by pushing the PB1S button. Octets are marked by letters A, b, C and d. By pushing the PB1L button, the entered values are stored and the clock returns to the menu item P21. © MOBATIME 16 / 52 800693.16...

  • Page 17: Manual Setting Of Default Gateway Ip Address

    NTP unicast synchronization. The item to be set is blinking. By pushing the PB2S button, the adjusted digit value is increased in steps of 1; by pushing the PB2L button, the value will be continuously increased. © MOBATIME 17 / 52 800693.16...

  • Page 18: Submenu For Displaying Ipv6 Addresses

    (011b) – f6.8e fifth part of the IPv6 address (100b) – s 38.ff. ixth part of the IPv6 address (101b) – fe.e.8 seventh IPv6 address (110b) – 4a.1.3 eighth part of iPv6 address (111b) © MOBATIME 18 / 52 800693.16...

  • Page 19: Control Of The Clock Using Ir Remote Control

    Note: When the time zone of displayed time and date (menu item P7) is set to the values U1 – U7 or U, the entered time and date is taken as UTC. © MOBATIME 19 / 52 800693.16...

  • Page 20: Menu For The Setting Of The Clock Parameters

    In menu item P2 (time constants for automatic switching over of values) set value U, then enter the submenu by pushing the SET button. The item to be set is blinking.The display shows the following: © MOBATIME 20 / 52 800693.16...

  • Page 21: Offset Setting For Time Synchronization

    1. Set value 1 for enabling the telnet support or value 0 for disabling it. By pushing OK, the entered values are stored and the clock returns to the menu item P19. By pushing ESC, the clock returns to P19 without saving. © MOBATIME 21 / 52 800693.16...

  • Page 22: Manual Setting Of The Ip Address Of The Clock

    A, b, C and d. By pushing OK, the entered values are stored and the clock returns to the menu item P23. By pushing ESC, the clock returns to P23 without saving. © MOBATIME 22 / 52 800693.16...

  • Page 23: Submenu For The Setting Of The Ntp Unicast Synchronization

    (011b) – f6.8e fifth part of the IPv6 address (100b) – s 38.ff. ixth part of the IPv6 address (101b) – fe.e.8 seventh IPv6 address (110b) – 4a.1.3 eighth part of iPv6 address (111b) © MOBATIME 23 / 52 800693.16...

  • Page 24: The Clock Menu Table

    0 - 64, A (automatically) synchronization source Type of 1 - 10, A (automatically) synchronization auto detection, applicable for: DCF, the Mobatime serial source code, MOBALine, WDT, IRIG-B or NTP autonomous operation without synchronization (check Line type synchronization by DCF signal...
  • Page 25 P 17 Parity n no parity o odd E even P 18 IP mode NTP, PoE: IPv4 / IPv6 dualstack WiFi: not supported NTP, PoE: IPv4 WiFi: IPv4 NTP, PoE: IPv6 WiFi: not supported © MOBATIME 25 / 52 800693.16...

  • Page 26: Ipv6 Adress Submenu

    First address received from DHCPv6 e.g. 2001:0db8:0000:0012:0000:0000:0000:1000 MANU Manually set address e.g. fec0:1234:0000:0000:f68e:38ff:fee8:4a13 PrEF Prefix of manually set address Range 0 – 128, default 64 GATE Default gateway obtained from SLAAC not yet e.g. 2001:0db8:0000:0012:0000:0000:0000:0001 supported © MOBATIME 26 / 52 800693.16...

  • Page 27: Control Of The Stopwatch Via Keyboard

    Data order 1/100 second <Minute>:<Second>.<Hundredths of second> 1 second <Hours>:<Minutes>:<seconds>. 1 minute <Hours>:<Minutes> 1 day <Days> By pushing the PB1L button, the entered values are stored and the clock returns to the “Stopwatch” display mode. © MOBATIME 27 / 52 800693.16...

  • Page 28: Control Of The Stopwatch Using Ir Remote Control

    © MOBATIME 28 / 52 800693.16...

  • Page 29: Setting Of Initial Time For Counting Down

    It is possible to control an external device such as sound devices. There is normally open contact (NO), normally closed contact (NC) and common contact (COM) on the relay port (JP21) available. © MOBATIME 29 / 52 800693.16...

  • Page 30: Stopwatch Menu Table

    Counter reset (to zero), or return to a preset (PB1L) time followed with counter stop Triggering the counter (PB3S) HOLD Stopping the counter (PB1S) Resetting the counter or return to a preset (PB1L) time, with counter stop © MOBATIME 30 / 52 800693.16...
  • Page 31 When counting is stopped, the dot is displayed after the last digit. Contact 1 – 30, 0 (function disabled) closing Time period of contact closing for stopwatches passing through zero, while operating in countdown mode, starting from a preset time moment. © MOBATIME 31 / 52 800693.16...

  • Page 32: Local Time Calculation

    Display time and date according to chosen time zone server time zone, incl. daylight saving time This setting is suitable for NTP and PoE digital clocks controlled by MOBATIME NTP servers which support the time zone server functionality. © MOBATIME 32 / 52 800693.16...

  • Page 33: Calculation Using Time Zone Entries Preconfigured By Moba-Nms Software

    See the chapter 15 with actual Time zone definition table. If you want to use the zone outside the internal time zone table, follow the "Custom Time Zone settings" appendix. © MOBATIME 33 / 52 800693.16...

  • Page 34: Non-Network Clock Operation

    Configure the jumper JP11 according to table (chapter 2.8) if the source of synchronization is a DCF signal, Mobatime serial code, polarized impulse line, MOBALine or IRIG-B. Choose the item P4 in main MENU (chapter 5) and set the type of synchronization. The auto detection mode (P4:A), when the type of synchronization signal is set automatically, is applicable for DCF signal, Mobatime serial code, MOBALine, IRIG-B, WTD.

  • Page 35: Synchronization And Time Setting - P5 Mode 1 And 3

    In case of the line fault the clock displays the right time information based on its own quartz time base. When the normal operation of the line resumes, the clock synchronizes with the incoming pulses. Slave clock controlled by MOBATIME serial code, MOBALine, or IRIG-B 10.4 •...

  • Page 36: Slave Clock Controlled By Supervised Rs485

    Items P14 to P17 are set automatically to 9600 baud, 8 bits, even parity, 1 stop-bit. In case of communication problems it is possible to lower the communication speed. The modification of the items P14 to P17 is necessary to proceed in all connected displays identically. © MOBATIME 36 / 52 800693.16...

  • Page 37: Ntp And Poe Clock Operation

    NTP server address 3 0.0.0.0 / 0:0:0:0:0:0:0:0 NTP server address 4 0.0.0.0 / 0:0:0:0:0:0:0:0 NTP request time [s] DNS server 0.0.0.0 / 0:0:0:0:0:0:0:0 SNMP manager 1 0.0.0.0 / 0:0:0:0:0:0:0:0 SNMP manager 2 0.0.0.0 / 0:0:0:0:0:0:0:0 © MOBATIME 37 / 52 800693.16...

  • Page 38: Network Parameters Assignation By Dhcp

    11.1.3 Manual setting through telnet • connect to the clock and make the needed settings by windows command telnet <IP address> example: telnet 192.168.0.190 • request for entering the password appears after connection (default password is 718084) © MOBATIME 38 / 52 800693.16...

  • Page 39: Setting Network Parameters Over Dhcpv6

    IP clock mode must be set to IPv6 mode (P18: 0/2). Menu item P25 must be set to 3 (default setting) or 1. The following SLAAC options can be processed: [3] Prefix info [5] MTU [24] Route info [25] RDNSS © MOBATIME 39 / 52 800693.16...

  • Page 40: Snmp

    65532 time zone client port number 65534 The menu item P19 must be set to value 1. See chapter 4.2.7 for setting the IPv4 multicast group address in the item P23 submenu. © MOBATIME 40 / 52 800693.16...

  • Page 41: Wifi Clock Operation

    P26 is reset to 1 and parameter P19 is set to the value of your chosen configuration • The NTP server must be set up using telnet with the command conf -u © MOBATIME 41 / 52 800693.16...

  • Page 42: Wifi 2.4/5 Ghz Version

    –? displays help for the command conf parameters • command wifi-n displays the wireless network setting • command wifi-? displays helpfor wifi parameters • it is necessary to end telnet by command exit © MOBATIME 42 / 52 800693.16...
  • Page 43 Example of setting network parameters using telnet – WPA and DHPCv4 (valid only for WiFi 2.4 / 5 GHz): • command wifi –s mobatime set network name (SSID) of new wireless network • command wifi –w 7 set version of used coding on PEAP •...

  • Page 44: Testing Mode, Parameter Reset

    Using the PB2 or + button on IR set the value behind the colon to 04 • Keep pushing simultaneously both buttons or the DISP button on IR, until the display shows FAC1 and clock makes reset © MOBATIME 44 / 52 800693.16...

  • Page 45: Firmware Update

    After entering the password, check if the firmware version is correct, if it isn’t, it is necessary to repeat the whole procedure. • Close the telnet window and end the program tftpd32 with the command exit. © MOBATIME 45 / 52 800693.16...

  • Page 46: Time Zone Table

    -3.5 Sun. Mar. (02:00) Sun. Nov. (02:00) Atlantic Time (Canada) Sun. Mar. (02:00) Sun. Nov. (02:00) La Paz Bogota, Lima, Quito New York, Eastern Time (US & Canada) Sun. Mar. (02:00) Sun. Nov. (02:00) © MOBATIME 46 / 52 800693.16...
  • Page 47 The Time Zone Table is usually updated every year. The current table is available for download under the following address: www.mobatime.com  Customer Area  Customer Support  Support Resources  Software Tools  Time Zone Table. In case your device is equipped with a newer version than shown in this manual, the current time zone settings should be checked.

  • Page 48: Engineering Data

    +- 12 – 30 V 3 - 7 mA MIN, CODE (on request) +- 30 – 60 V 3 - 7 mA IRIG B 20 mVpp – 2 Vpp 20 uA – 2 mA © MOBATIME 48 / 52 800693.16...

  • Page 49: Accessories And Maintenanc

    The following circumstances are excluded from the guarantee: inappropriate handling or interventions chemical influences mechanical defects external environmental influences (natural catastrophes) • Repairs during and after the guarantee period are assured by the manufacturer. © MOBATIME 49 / 52 800693.16...
  • Page 50 © MOBATIME 50 / 52 800693.16...
  • Page 51 © MOBATIME 51 / 52 800693.16...
  • Page 52 19 ch. du Champ-des-Filles, CH-1228 Plan-les-Ouates Tel. +41 34 432 46 46 / Fax +41 34 432 46 99 Tel. +41 22 884 96 11 / Fax + 41 22 884 96 90 moserbaer@mobatime.com / www.mobatime.com export@mobatime.com / www.mobatime.com SALES SWITZERLAND...
