Installer Options Menu

The LCD keypads provide Keypad Option and Keypad Diagnostic menus to allow installers and service technicians to
configure and test keypad operation.
Accessing Installer Options
You can only access the Installer Options Menu through the User Options function. Hold down the <— and CMD keys
for two seconds to display SET BRIGHTNESS. Enter the code 3577 (INST) and press CMD. The display changes to KPD
OPT (keypad options) KPD DIAG (keypad diagnostics) and STOP.
The Keypad Options menu allows you to set the keypad address, select Supervised or Unsupervised mode, change the
default keypad message, selectively enable the 2-button Panic keys, Soft-Shunt, Request-to-Exit, and set entry card
options.
Note: All programming options display on all keypads, however, actual operation for some programming options is
restricted to the listed keypads.
Programming Keypad Options
KPD KPD
OPT DIAG STOP
CURRENT KEYPAD
ADDRESS: 01
KEYPAD MODE:
*SUP UNSUP
DEFAULT KEYPAD
MSG:
ARM PANIC KEYS:
*PN *EM *F1
7/0 PANIC
NO YES
ENABLE:
ACTIVATE ZONE 2
NO YES
SHUNT:
690/690F/790/790F/693/793 Installation Guide
Keypad Options (KPD OPT)
To program keypad options, press the left Select key under KPD OPT. The display
changes to CURRENT KEYPAD ADDRESS: # #.
Keypad Address
Set the keypad address from 01 to 05 with the XRSuper6 and XR20, from 01 to 08 with
the XR40, XR200, and 01 to 16 with the XR200-485 and XR500 Series. The factory
default address is set at 01. To change the current address, press any Select key and
then enter the new address using the appropriate number keys on the keyboard. It is
not necessary to enter a leading zero for addresses 01 to 09.
Keypad Mode
Configure the keypad for either Supervised or Unsupervised operation. Keypads with
zones connected to them must be supervised. Supervised keypads cannot share
addresses with other keypads.
Unsupervised keypads can operate with other unsupervised keypads sharing the same
address. Zones cannot be used on unsupervised keypads. To change the current
setting, press the Select key under SUP or UNSUP. An asterisk appears next to the
selected option.
Note: Unsupervised addresses cannot be used when Device Fail Output has a
programmed value other than zero.
Default Keypad Message
Enter a custom message of up to 16 characters to appear on the keypad display top line
whenever that line is not used for any other purpose. Press any Select key to clear the
current display and use the data entry keys to enter a new custom display.
Arm Panic Keys
Use this option to configure the top row Select keys as 2-button Panic keys. To enable
or disable a Panic, press the Select key under the appropriate display: PN (Panic), EM
(Emergency), and FI (Fire). Once the panic is enabled, an asterisk displays next to the
description. Refer to the Panic Key Options section earlier in this document.
7/0 Panic
Use this option to configure the 7 and 0 keys as a 2-button Panic feature. To enable
the 7/0 Panic, select YES. To disable the option, select NO. Default is NO. In a panic
situation simply press and hold the 7 and 0 keys for one-half (1/2) second. Refer to the
Panic Key Options section earlier in this document.
Zone 2 Shunt (793 only)
Select YES to enable the Soft-Shunt™ option on zone 2 as described earlier in this
document. This zone provides the Soft-Shunt™ for door contacts. This zone must be
programmed into the panel.
