693/793 User's Guide
There are three different sections: Keypad Arming and Disarming, Keypad Door Strike, and Keypad Entry Delay. All of
the examples below assume that CLOSING CODE is YES in panel programming.

Keypad Arming and Disarming

Area System Arming and Disarming
Press CMD, the keypad displays ARM DISARM. Press the Select key under either option. The keypad displays ENTER
CODE: -. Present your card to the keypad reader. Once validated by the system, all areas assigned to your code arm
or disarm automatically and the 793 keypad Door Strike relay activates.
ABC SECURITY
ARM DISARM
POWER
Select NO to arm or disarm individual areas.
Select YES, or simply wait, to automatically arm or disarm
all areas for which you are authorized.
All/Perimeter System Arming and Disarming
Press CMD, the keypad displays PERIM ALL (when arming) or DISARM? Press the select key under the desired option.
The keypad displays ENTER CODE: -. Present your card to the reader. Once validated by the system, the selected
areas arm or disarm automatically. On 793 keypads, the Door Strike relay then activates.
Home/Away System Arming and Disarming
Present your card to the reader. If the system is armed, once the card is validated, all areas are disarmed. If the
system is disarmed when you present your card, once the card is validated, all areas are armed in the AWAY mode.
Digital Monitoring Products
10
ABC SECURITY
ENTER CODE: –
POWER
Figure 9: Area Arming and Disarming
PERIM ALL
or
DISARM?
POWER
The system arms or disarms
the areas and activates the
door strike relay.
Figure 10: All/Perimeter Arming and Disarming
ABC SECURITY
ENTER CODE: –
POWER
POWER
690/690F/790/790F/693/793 Installation Guide
ABC SECURITY
ALL? NO YES
POWER
