INSTALLING THE IQ REMOTE PG
TABLE STAND (OPTIONAL)
3
4
5
2
1
1. Locate the optional
2. Pull battery tab to remove.
4. Insert the barrel from the
5. Secure with the top screw so
table stand.
power supply into the barrel
that the panel cannot be
3. Position the table stand
jack in the back of the panel.
removed from the table stand.
onto the back of the panel
and then slide up, making
sure that all 4 tabs hook into
the back of the panel.
