INSTALLING THE IQ REMOTE PG

POWERING THE PANEL

Connect power supply.
WARNING!
Use a 12vDC
If using the provided cable, the "striped" wire is (+)
Note: Power supply shall be located within same room as control unit
Power Supply ONLY
QOLSYS CONFIDENTIAL AND PROPRIETARY
PAGE
Press and hold the power button on
the back right side of the panel for 3
seconds to power up.
10
OF
42
