INSTALLING THE IQ REMOTE PG

WALL MOUNT

Note: For UL/ULC Commercial Burg installations (UL2610/ULC-S304 Security Level II compliant) use only wall mount option.

This product when installed as per these instructions does not present the risk of fire, electric shock, or injury to persons.

1. Mount the bracket to the

2. Pull battery tab to remove.

4. Position the panel onto the

5. Secure with the top screw so

wall using appropriate

backplate and then slide down,

that the panel cannot be

hardware ensuring it is level.

3. Insert the barrel from the

making sure that all 4 tabs hook

removed from the backplate.

power supply into the barrel

into the back of the panel.

A screw shall be used in all 4

jack in the back of the panel.

screws holes for UL2610

installations
