MAINTENANCE

BATTERY REPLACEMENT

CAUTION: Do NOT use a screwdriver or anything sharp that could puncture the battery.
2
Battery
3
QOLSYS CONFIDENTIAL AND PROPRIETARY
PAGE
1. Power down panel: Press and hold the power
button on the side of the IQ Remote PowerG
for 2 seconds and select "Power Down" from
the pop up
2. Remove Battery Door: Remove the panel
from the backplate or table stand and then
use a small screwdriver to remove the plastic
door covering the battery.
3. Remove Battery: Pull the fabric tab that is
located under the battery to remove it from
the panel.
4. Install New Battery: Install the new battery
paying careful attention to polarity and being
sure to place the fabric pull tab under the
battery to make future removal easier.
Re-install Battery Door and screw, then re-
mount to backplate or table stand.
