- Page 1 HDMI Distributor User Manual Model : HAE01 4K60Hz HDMI Audio Extractor with Up/down Scaler Smart Cabling & Transmission Corp. V1.0_1902142...
- Page 2 HAE01 Introduction HAE01 is an HDMI multifunctional tool allowing you to extract HDMI audio to integrate external audio equipment, such as amplifiers, AV receivers, etc. Additionally, the up/down scaling function, which converts 1080p signal to 4K, or 4K signal to 1080p, allows you to save extra cost on a new HDMI monitor.
-
Page 3: Installation View
User Manual HAE01 Installation View Application 1 : 4K HDMI Audio Extrator Application 2 : 4K HDMI Up/Down Scaler with Audio Extrator HDCP 2.2 to 1.4 and 4:4:4 to 4:2:0 and Up/Down Scale Capable Full OSD operation for all setup/EDID management... -
Page 4: Audio Mode
User Manual HAE01 MENU Main Menu Sub Menu Sub Menu Function OUTPUT 1 MODE NORMAL Output video same as input Video UPSCALE 1080P Upscale to 4K EXIT Exit Sub Menu OUTPUT 1 Output color subsampling same as Input NORMAL SUBSAMPLING 4:4:4 4:2:0... -
Page 5: Panel View
User Manual HAE01 Panel View LED Indication Color GREEN Power BLUE Output 1 Output 2... -
Page 6: Troubleshooting
3. Up/down scale mode only support resolution conversion, frequency will be not changed. 4. Under HDMI 2.0 mode, must use Premium certified HDMI cable. HAE01 Package Include HAE01 x 1 pcs DC5V 1Amp Power Adapter x 1 pcs DB9 (0F)/3.5mm STEREO PHONE JACK x 1 pcs... -
Page 7: Specification
User Manual HAE01 Specification ITEM NO. HAE01 Support Compliance HDMI 2.0, HDCP 2.2, 3D, HDR Max. Video Resolution 4K@60Hz 4:4:4 Video Bandwidth 18 Gbps Audio Format 7.1 LPCM 192KHz, Dolby TrueHD, DTS-HD MA Ports & Interfaces Video Input 1 x HDMI Type A...
