- Page 1 HDMI Distributor User Manual Model : HAE01 4K 60Hz HDMI 1 In 2 Out Audio Extractor(HDMI/SPDIF/Stereo) with Up/down Scaler Smart Cabling & Transmission Corp. V1.0 V1.0...
-
Page 2: Installation View
HAE01 Introduction HAE01 is an HDMI multifunctional tool allowing you to extract HDMI audio to integrate with external audio equipment, such as amplifiers, AV receivers, etc. The video scaling function can up/down scale the resolution from 1080p to 4K, or 4K to 1080p, saving cost on a new HDMI monitor. With the built-in 5-way joystick switch, you can operate and setup all the functions in an easy way. -
Page 3: Panel View
User Manual HAE01 Panel View LED Indication LED Name LED Color Function Power GREEN On/ Off Power On/ Off Output 1 BLUE On/ Off Output 1 linked/ unlinked Output 2 RED On/ Off Output 2 linked/ unlinked... - Page 4 User Manual HAE01 RS232 Define DB9(F)/3.5mm STEREO PHONE DB9(F)/3.5mm STEREO PHONE JACK JACK RS232 3.5 mm Phone Jack Footprint Define Footprint Define Pin 2 Pin 1 Pin 3 Pin 2 Pin 5 Pin 3 5 way Joystick Switch Function Down...
-
Page 5: Audio Mode
User Manual HAE01 OSD Menu Main Menu Submenu Description NORMAL Output video same as input video OUTPUT 1 MODE UPSCALE 1080P to 4K EXIT Exit submenu NORMAL Output color subsampling same as Input OUTPUT 1 4:4:4 4:2:0 Color subsampling from 4K 4:4:4/4:2:2 to 4:2:0... -
Page 6: Troubleshooting
User Manual HAE01 Trouble Shooting CEC function only works at the output 1. Up/down scale mode only support resolution conversion, refresh rate is not able to be changed. It’s recommended using Premium certified HDMI cable Under HDMI 2.0 mode. Package Includes... -
Page 7: Specification
User Manual HAE01 Specification ITEM NO. HAE01 Support Compliance HDMI 2.0, HDCP 2.2, 3D, HDR Max. Video Resolution 4K@60Hz 4:4:4 Video Bandwidth 18 Gbps Audio Format 7.1 LPCM 192KHz, Dolby TrueHD, DTS-HD MA Ports & Interfaces Video Input 1 x HDMI Type A...
