20 Abstand zum nächsten Objekt.
20 distance au prochain objet.
20 distance from the next object.
C
B
A
8301147GB/160808
Alle Maße in mm. Toutes les mesures en mm. All measures in mm.
2
>800
- schraffierte Fläche Freiraum für Servicezwecke.
- Section hachure espace libre pour service après vente.
-Hatched section clear area for maintenance.
-
We reserve the right to make technical changes -
3
20 Abstand zum nächsten Objekt.
20 distance au prochain objet.
20 distance from the next object.
INSTALLATION
V.819252
4
- Geräteaufstellung auf
Sylomerstreifen (im Beipack).
- Installation de l'appareil sur
bande de Sylomer (ci-inclus)
- Device installation on
Sylomer strip (included)
Oberkante Fertigfußboden
Bord supérieur sol
Upper edge finished floor
