- Page 1 Brine/Water Heat Pumps Operating Manual SWC H1 series 83057200dUK – Translation of the original operating manual...
-
Page 2: Table Of Contents
Table of contents 11 Maintenance ............19 11.1 Basic principles ..........19 11.2 Maintenance as required ......19 About this operating manual ......3 Validity ..............3 condenser ............19 Reference documents ........3 11.4 Yearly maintenance ........19 ..3 12 Faults ..............20 Contact ............4 ..20 Safety ...............4 13 Dismantling and Disposal ......20 Intended use... -
Page 3: About This Operating Manual
About this operating manual This operating manual is part of the unit. operating manual carefully and follow it for all Symbol Meaning activities at all times, especially the warnings and safety instructions. Safety-relevant information. Warning of physical injuries. Keep the operating manual to hand at the unit and hand over to the new owner if the unit changes DANGER Indicates imminent danger resulting... -
Page 4: Contact
Addresses for purchasing accessories, for service Heating installer cases or for answers to questions about the unit and this operating manual can be found on the internet at Plumbing installer Germany: www.alpha-innotec.de www.alpha-innotec.com During the warranty and guarantee period, service authorised by the manufacturer. Safety 2.3 Personal protective equipment... -
Page 5: Disposal
2.5 Disposal components, e.g. heat exchanger, pipes, pumps Batteries Material fatigue bubbles cushion formation environment. coatings, deposits, and associated noises, e.g. compatible way according to the local regulations. Media harmful to the environment Note and follow the information in this operating Improper disposal of environmentally harmful media Collect media safely. -
Page 6: Description
Description 1 Electrical switch cabinet 2 Heating element 3 Manual output control heating element 3.1 Layout 5 Valve motor NOTE 6 3-way changeover valve, heating circuit/ This section essentially names domestic hot water 7 Heating circuit/hot water circulation pump described in this operating manual. 8 Module box Housing with unit components Rating plate... -
Page 7: Accessories
3.2 Accessories 5 Evaporator 6 Heat source circulation pump The following accessories are available for the unit through the manufacturer's local partner: if the control is mounted on the wall NOTE The hose connectors are not part of the scope of delivery with all KFE ball valves. Changeover valve, domestic hot water Room thermostat for switching the cooling Control unit... -
Page 8: Operation And Care
Delivery, storage, transport pump does not switch to high-pressure fault if all and installation heating circuits are closed. The integrated vibration isolators for the heating circuit and heat source prevent structure-borne sound and vibrations from ATTENTION Damage to the housing and the unit components into the building. - Page 9 way according to local regulations. NOTE The module box can be removed for transport front panel in the place of installation. Dismantle housing panels for transport with Notes on safe transport handcart or carrying the unit The housing with the unit components and the module “Technical data / Scope of supply”, To avoid damage to the housing panels: to property if the housing with the unit components...
-
Page 10: Installation
5.4 Installation Housing panels are dismantled. To avoid damage: On a handcart, load the unit on its Installation room and space requirements side only. NOTE Note and follow the local regulations and standards regarding the installation room and space requirements. The table shows the regulations as per EN 378-1 relevant in Germany. -
Page 11: Installation And Connection
Installation and connection 6.1 Dismantle the module box ATTENTION If the module box is tilted by more than 45°, compressor oil runs into the cooling circuit. Do not tilt the module box by more than 45°. NOTE If necessary the module box can be dismantled for easier transport of the unit or for service reasons. - Page 12 10. Disconnect the hydraulic connections; to do this, push the pipes apart as far as necessary. Remove the insulation on the hydraulic connec- tions. 11. Remove the 2 side retaining screws. Remove 3 clips on the hydraulic connections. Use spanner size SW 37 to unscrew the heating Subject to change without notice | 83057200dUK –...
-
Page 13: Install The Module Box
6.3 Install the hydraulic connections 14. Slowly and carefully pull out the module box by ATTENTION pipes are damaged Damage to the copper pipes due to unacceptable loading! 15. Pull out the module box completely and place it on the boards. Secure all connections against twisting. -
Page 14: Connect The Electrical Cables
Connect the unit to the heat source and heating circuit the connections Strip the sheathing of all cables to the external heat source and heating circuit. loads before laying in the cable duct of the control box. Insert the vent at the highest point of the heat source and the heating circuit. -
Page 15: Installing The Control Panel
6.5 Installing the control panel NOTE The control can be inserted in a recess in the front panel of the unit or can be installed on the wall. Insert the control in the unit and connect 200 mm “Dismantle housing panels for transport with handcart or Push the cable through the opening in the front together and push out of the openings. -
Page 16: Remove The Front Panel Of The Module Box
Route the LIN bus cable from the top right-hand Advantages of low-salt operation: side at the rear from the heat pump and plug into Low corrosion-promoting properties the control at the bottom. No formation of mineral scale Ideal for closed heating circuits the system by adding chemicals The following antifreezes mixed with water are... -
Page 17: Vent The Circulation Pump Of The Heat Source
7.4 Vent the circulation pump of the heat source The front panel of the module box is unscrewed. Place vessel for collecting discharging liquid un- der the outlet. Undo screw-on cap in the middle of the circula- tion pump. Turn the spindle of the 3-way changeover valve so that the rounded side of the spindle points in the 3-way changeover valve. -
Page 18: Insulate Hydraulic Connections
Ensure that the U-clip has latched into position correctly: Valve motor sits securely on the 3-way changeo- ver valve. NOTE The activities in this section are only nec- Both prongs of the U-clip sit on the lug. The tips of the U-clip are visible by approx. 2 mm the maximum return temperature can be exceeded and the heat pump switches to 10. -
Page 19: Commissioning
10 Commissioning 11 Maintenance Relevant planning & design data of the system is NOTE documented in full. We recommend that you sign a maintenance agreement with accredited heating of operation of the heat pump system. company. System is air-free. 11.1 Basic principles been completed successfully. -
Page 20: Faults
12 Faults 13 Dismantling and Disposal Read out the cause of the fault via the diagnostics 13.1 Dismantling program of the heating and heat pump controller. Unit is safely disconnected from the power supply Contact the local partner of the manufacturer or the factory's customer service. -
Page 21: Technical Data / Scope Of Supply
Technical data / Scope of supply SWC 42H1 – SWC 62H1 Performance data: Heating output / COP SWC 42H1 SWC 62H1 at B0/W35 operating point to EN14511 4,54 5,80 4,80 at B0/W45 operating point to EN14511 4,70 3,58 5,31 3,50 Heating capacity at B0/W55 operating point to EN14511 4,53... -
Page 22: Swc 82H1 - Swc 102H1
Technical data / Scope of supply SWC 82H1 – SWC 102H1 Performance data: Heating output / COP SWC 82H1 SWC 102H1 at B0/W35 operating point to EN14511 7,50 4,80 10,30 4,80 at B0/W45 operating point to EN14511 6,84 3,56 3,57 Heating capacity at B0/W55 operating point to EN14511 6,62...
