VENTILATION HEATING CIRCUIT

Setting of the pressure differential valve:

Put a vent at the top point of the heating circuit in the flow

(heating circuit water outlet)!

The bypass valve

must be set so that

the spread between

flow and return is

< 10K (standard-

setting 200 mbar and

secured by lacquer)

Venting of the device:

The heat pump vents automatically.

When filling or emptying the heating circuit or the brine circuit��

the vent valves of the respective safety components open.

8301147GB/160808

Filling- and discharge-

device for the brine circuit::

Filling and discharge device

for the heating circuit:

We reserve the right to make technical changes -
