FREE PRESSURE dROP CURVES
SWC 60H/S
V.812144
Free pressure (bar)
Freie Pressung (bar)
0,9
0,8
0,7
0,6
0,5
0,4
0,3
0,2
0,1
0,0
0,0
32
0,5
1,0
1,5
Heating circuit water-/domestic water-/brine flow rate (m3/h)
Heiz-/Brauchwasser-/ Solevolumenstrom (m
-
We reserve the right to make technical changes -
SWC60H/S
- Free pressure heating system
freie Pressung Heizung
- Free pressure brine system
freie Pressung Sole
2,0
2,5
3,0
3
/h)
3,5
8301147GB/160808
