Type of heat pump
CE-certified
Assembly
Protection class
Performance data without pumps
Heating capacity/COP
Noise
Sound pressure level measured at a distance of 1 m from the machine (in free field)
Sound efficiency level
Application limits
Operating temperature limits for heating circuit water
Operating temperature limits for brine
Device
Size. width x depth x height (without connections and safety components)
Total weight / weight cooling (option)
Type of coolant / capacity
Heating circuit water / domestic water loading circuit
Minimum / nominal / maximum water flow rate
Free compression heat pump at a flow rate of 1800 l/h (range approx. 7K)
Heat Source
Minimum / nominal / maximum brine flow rate
Free compression heat pump at a brine flow rate of 2600 l/h (range approx. 4K)
Minimum brine concentration/frost protection up to
Capacity of brine expansion tank / primary pressure (included)
Connections
Heating circuit water
Sole
Dirt filter connections 1" flange (fitted in the brine circuit upstream from the heat pump)
Electrical information
Nominal voltage / heat pump fuse protection1)
Nominal voltage / heating element fuse protection1)
Nominal voltage / control voltage fuse protection1)
Heating element
Maximum machine current within application limits
Maximum theoretic compressor flow (Imax, overcurrent relay) A
Power consumption / electricity consumption/ acc. to EN 14511
Power consumption to heating pump/domestic hot water pump at a nominal rate of flow kW
Power consumption to brine pump at a nominal rate of flow
Direct initial current with softstarter
8301147GB/160808
B0/W35 acc. to EN255
B0/W35 acc. to EN14511
B0/W50 acc. to EN14511
B-5/W35 acc. to EN14511
B-5/W50 acc. to EN14511
-
We reserve the right to make technical changes -
TECHNICAL dATA
SWC 140 S
Brine / water
CE
Indoors
IP24
kW/- 14,7 / 4,6
kW/- 14,5 / 4,4
kW/- 13,6 / 2,9
kW/- 12,7 / 3,9
kW/- 12,1 / 2,5
dB(A) 45
dB 58
° C 20 to 65° C
° C -5 to 25°
mm 650 x 500 x 1550
kg 212
- / kg R407c / 2,7
l/h 1200 / 2500 / 3100
bar 0,56
l/h 2600 / 3500 / 4300
bar 0,38
% / ° C 25 / -13
l / bar 18 / 0,5
R5/4" AG
R5/4" AG
to be fitted on-site
- / A 1NPE 230VAC 50Hz / 32C
- / A 1NPE 230VAC 50Hz / 10C
- / A 1NPE 230VAC 50Hz / 10C
kW 9
A 26,8
A 40,0
kW / A 3,29 / 14,3
0,2
kW 0,25
A 58
V.813182
