- Page 1 HD-TVI/ AHD/ HD-CVI/ CVBS Distributor Series User Manual Model : CD1664HD 16 x 64 HD-TVI/AHD/HDCVI/CVBS Video Distributor in 2U Rack Smart Cabling & Transmission Corp. V1.0...
-
Page 2: Installation View
User Manual CD1664HD Introduction CD1664HD is a video distributor that can split 16 HD-TVI/ AHD/ HDCVI/ CVBS signals into 64 ones with up to 4K (8MP) resolution. Features Extends and splits 16 video signals into 64 ones. Supports HD-TVI, AHD, HDCVI, 960H, NTSC, PAL video signal. - Page 3 User Manual CD1664HD Slide switch at VIDEO+DATA Dip Switch Mode Function VIDEO Output 1 support video only. VIDEO + DATA Output 1 support HD camera video with data control signal Panel View Cable & Transmission Distance...
- Page 4 User Manual CD1664HD Link cable recommend use high quality 75ohm coaxial RG59/RG6U cable. The transmission distance will be affected by different quality of Camera, DVR and BNC connector, cable, installation…etc. LED Indication Orange Power ON/OFF Caution Output 1 under Video+Data mode, the output must connect with HD-DVR. Not allow to connect with CVBS...
-
Page 5: Specifications
User Manual CD1664HD Specifications ITEM NO. CD1664HD Support Video Format HD-TVI, AHD, HDCVI, 960H, NTSC, PAL Max. Video Resolution Video Bandwidth 100MHz 0.1dB Gain Flatness Ports & Interfaces Video Input 16 x BNC (1V p-p, 75Ω) Video Output 64 x BNC (1V p-p, 75Ω)
