SC&T RS007 User Manual

Rs232/rs485/rs422 to ethernet ( tcp/ip) converter
Hide thumbs

Advertisement

Table of Contents

Data Transmission Series
User Manual
Model :
RS007
RS232/RS485/RS422 to Ethernet ( TCP/IP) Converter
Smart Cabling & Transmission
V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS007 and is the answer not in the manual?

Questions and answers

Related Manuals for SC&T RS007

Summary of Contents for SC&T RS007

  • Page 1 Data Transmission Series User Manual Model : RS007 RS232/RS485/RS422 to Ethernet ( TCP/IP) Converter Smart Cabling & Transmission V1.0...

  • Page 2: Application Diagram

    Introduction RS007 is a data converter that converts RS232, RS422 or RS485 to TCP/ IP signal. The converter can setup up to one client and 4 servers and easily configure the parameters via a PC software or a web browser..

  • Page 3: Panel View

    Panel View Interface Functionality RJ45 Connector To use network cable to connect RS007 with PC (Refer to Description 1). Power LED Indication To indicate the power status (Refer to Description 2). Rx LED Indication To indicate Rx connection status (Refer to Description 3).
  • Page 4 User Manual RS007 Description RJ45 LED Data Rate Disable Enable Data Transferring 100Mbs Yellow Off Yellow On LED Blinking 10Mbps Green Off Green On LED Blinking RJ45 Pin out (TIA/EIA-568-B) (PIN TIA/EIA-568B) Wire Color Orange-white Orange Green-white Blue Blue-white Green...
  • Page 5 User Manual RS007 4 Pin Terminal Be aware of the connection of the positive and the negative electrode RS485 & RS422 Wiring RS485 Wiring RS422 Wiring RS232 Port 5.1 Among RS232, RS485, and RS422, only one signal can be transferring at once.
  • Page 6 User Manual RS007 Setting via WebGUI RS007 setup can be accomplished via IE and other browsers Scan the QR code in the left to follow the instructions Or type in the URL: https://youtu.be/1XcjLKQRle4 You can also refer to the diagram below to set up the device.
  • Page 7 User Manual RS007 Basic Serial Settings Data Baud Rate: 1200~115200bps Data Bits: 5, 6, 7, 8 Data Parity: None, Even, Odd Stop Bits: 1 or 2 Flow Control: None, Hardware, Xon/Xoff RS485: Sleep, Single Twisted Pair HD, Double Twisted Pair FD (Slave), Double Twisted Pair FD (Master)
  • Page 8 RS007 Static IP Address The IP address of the RS007 is consist of 4 set of numbers separated by “ . “ (Dot symbol). Use distinctive IP address for different networking devices or they may conflict with each other’s If DHCP client mode is enabled, there will be a DHCP server on the network, this field will be assigned by DHCP server automatically.
  • Page 9 User Manual RS007 Advance Firmware Upgrade Settings TFTP Server IP Enter IP address in TFTP server box to update firmware. File Name File name of firmware in TFTP server. E-mail Server Address IP address or host name of SMTP server to send E-mail.
  • Page 10 User Manual RS007 Security Change Username Setting Enter new username and apply to change. Change Password Setting Enter old password, new password and confirm password to change password. Accessible IP Setting IP #1~4: IP address of accessible devices. Control: Enable or disable access permission of IP addresses entered above.
  • Page 11 User Manual RS007 Setting via PC Software Open the software (AXR2E Configuration Utility) in the attached CD to configure your RS007. Configuration Guide Scan the QR code in the left to watch the tutorial video Or type in the URL: https://youtu.be/ohoRTzaJDN0...
  • Page 12 User Manual RS007 Make a “Ping” until the window responds the information as shown. Establish a permanent connection by clicking on “Connect”. The “Connect” button will turn to “X Disconnect”, and then the window will show your IP address is successfully connected.
  • Page 13 You have at your disposal 3 window where to edit your strings to the peripheral device through the RS007. The single string is sent only when pressing the button “Send”. ASCII and HEX characters can be mixed. ASCII are written as they are, HEX are preceded by $. In the example shown, P0$0D means that the characters sent on RS232 line will be: -ASCII “P”...

  • Page 14: Troubleshooting

    In one-to-many mode, please update the SERVER side to the assigned firmware and change the connection type to UDP form. In one-to-many mode, please make sure that the SERVER is activated before the CLIENT or that both are activated at the same time to avoid connection errors. RS007 DOES NOT support Modbus communication protocol.

  • Page 15: Specification

    User Manual RS007 Specification ITEM NO. RS007 Support Standard RS232, RS485, RS422, Ethernet Max. Baud Rate 1200 to 115200 bps Network Bandwidth 10/ 100 Mbps Communication TCP Server, TCP Client, UDP Max. Transmission Distance 100M over CAT5e cable Ports & Interfaces...
