- Page 1 HD-TVI/ AHD/ HD-CVI/ CVBS Distributor Series User Manual Model : CD104HD 1 x 4 HD-TVI/AHD/HDCVI/CVBS Video Distributor Smart Cabling & Transmission Corp. V1.0...
- Page 2 User Manual CD104HD Introduction CD104HD is a video distributor that can split an HD-TVI/ AHD/ HDCVI/ CVBS signal into 4 ones with up to 4K (8MP) resolution. Features Extends and splits a video signal into 4 ones. Supports HD-TVI, AHD, HDCVI, 960H, NTSC, PAL video signal.
- Page 3 User Manual CD104HD Panel View Cable & Transmission Distance Link cable recommend use high quality 75ohm coaxial RG59/RG6U cable. The transmission distance will be affected by different quality of Camera, DVR and BNC connector, cable, installation…etc. LED Indication GREEN Power ON...
- Page 4 User Manual CD104HD Specifications ITEM NO. CD104HD Support Video Format HD-TVI, AHD, HDCVI, 960H, NTSC, PAL Max. Video Resolution Video Bandwidth 100MHz 0.1dB Ports & Interfaces Video Input 1 x BNC (1V p-p, 75Ω) Video Output 4 x BNC (1V p-p, 75Ω)
