AquaLink RS OneTouch™ | Owner's Manual
®
PUMP WILL TURN OFF AFTER COOL DOWN CYCLE
that the filter pump is circulating water to cool down the heater. The filter pump will
continue to run for five minutes to protect the heater from damage, whenever the
heater has fired and has been off for less than five (5) minutes.
PUMP WILL TURN ON AFTER DELAY
spa switching. The AquaLink RS waits 35 seconds while the valves turn from pool
position to spa position (or vice-versa) before activating the filter pump.
SENSOR OPEN
or is malfunctioning. Call your pool service person to resolve this problem. NOTE
If the message reads Water TEMP Open, the heater will not fire. If
message Air TEMP OPEN is displayed, freeze protection will not
operate correctly.
SENSOR SHORT
or is malfunctioning. Call your pool service person to resolve this problem. NOTE
If the message reads WATER TEMP SHORT, the heater will not fire.
If the message AIR TEMP SHORT is displayed, freeze protection will
not operate correctly.
SERVICE MODE
power center and is not operational. Service mode is used by the pool service person
to aid them in servicing the pool. The Controller will not be functional until the switch
at the Power Center is moved back to AUTO mode.
SPA WILL TURN OFF AFTER COOL DOWN CYCLE
Mode (water is circulating to the spa) and the Spa button is pressed to switch water
circulation to the pool, the system will not switch to Pool Mode for five minutes, and
will continue to circulate the water (if the heater has fired and has been off for less
than five minutes). This delay allows water to cool the heater down by circulating
water through it, preventing equipment damage.
TIMED AUX ON, WILL TURN OFF AFTER 30 MINUTES
that a timed auxiliary (usually a blower) has been activated and will turn off after
30 minutes. Some labels (e.g., blower, fill line) have a built-in 30 minute shut off.
SPILLOVER DISABLED WHILE SPA IS ON
spa spillover is pressed while in spa mode (water circulation is to spa). The spillover
requires that water circulation is to pool in order to operate. The spillover will activate
when the system switches back to pool mode.
TIMEOUT MODE
the Power Center and is not operational. Time Out mode is used by the pool service
person to aid them in servicing the pool. The Controller will not be functional for
three hours, or until the switch at the Power Center is turned back to AUTO mode.
This error message indicates that the sensor is not installed properly
This error message indicates that the sensor is not installed properly
This message indicates that the Controller has been locked out from the
This message indicates that the Controller has been locked out from
ENGLISH
This message indicates
This message is displayed during pool/
When the system is in Spa
This message indicates
This message is displayed when the
