• Valve durations are adjustable from
OFF to 240 minutes, in increments
of 1 minute to 240 minutes, or in
increments of 10 minutes from 10
to 60 minutes, or in increments
of 30 minutes from 60 to 240
minutes.
4.6.5.(D) COMPLETING/CONTINUING SPRINKLER PROGRAMMING
MENU/HELP
SYSTEM SETUP
• A Summary screen appears after
pressing CONTINUE with start
times of each program for review.
• Press EDIT to continue
programming, and press DONE to
return to the SPRINKLER SETUP
screen.

4.7 CONTROLS

4.7.1 RS INTERLINK (PWR CTR B)

EQUIPMENT ON/OFF
RS Interlink is used to set a single
controller's access to two (2)
Power Centers on the AquaLink
RS system. Select PWR CTR B
to access second power center
controls.
ENGLISH
SPRINKLERS
Valve 5:
Valve 6:
Valve 7:
Valve 8:
Highlight an item
and press SELECT
Aux7
Extra Aux
Pwr Ctr B
Spa Mode
AquaLink RS OneTouch™ | Owner's Manual
®
• If the end time of an enabled
program overlaps with the start
time of a second enabled program,
the second program delays until
the first program is complete. The
master valve will remain activated
between programs.
Set Duration
Program 2
10 MIN
OFF
OFF
OFF
Continue
Off
Off
