4.5.4 SET LAMINAR PULSE

MENU/HELP
SYSTEM SETUP
Select to assign a Laminar Light
to an auxiliary relay.
• Laminar Pulse Control must
be labeled to an auxiliary prior
to operating this feature. See
Section "4.3.5.(a) Label Aux",
for more details.

4.5.5 DIMMERS

MENU/HELP
SYSTEM SETUP
Select to assign auxiliary buttons to
control a dimmable switch.
• An optional Light Dimming
relay must be installed and only
120 VAC lighting (or suitable
transformer-driven lights) can be
dimmed.
• An "X" will show next to
selected auxiliaries. Select all
items connected to light dimming
modules. Press BACK when done.

4.6 SPRINKLER SYSTEM (SPRINKLERS)

EQUIPMENT ON/OFF
Select to access the SPRINKLERS
sub menu.
• Set up start and run time
programming via Sprinklers Setup
menu in the System Setup menu.
See Section "4.6.5 Programming
Sprinkler System" for more
details.
ENGLISH
Aux1
LABEL AUX
Aux2
Aux3
Aux4
Aux7
Solar Priority
Assign JVAs
Dimmers
Color Wheels
Spa Switch
Spa Link
Service Info
Clear Memory
Aux1
Aux2
Aux5
Aux6
Aux7
Extra Aux
Sprinklers
Spa Mode
Clean Mode
All Off
Filter Pump
Spa
Pool Heat
AquaLink RS OneTouch™ | Owner's Manual
®
Label Aux
Label Aux2
Light Labels
Garden
Laminar Plsr
Left
More
System Setup
More
Dimmer Setup
Off
Off
Off
Off
Off
Off
Off
Off
Off
Off
Off
More
Label Aux2
Current Label
Aux2
General Labels
Light Labels
Wtrfall Labels
Custom Labels
Label Aux
Aux1
Laminar Plsr
Aux3
Dimmer Setup
Warning
Optional
Dimmer Module
Must Be
Installed
Ok
Go Back
Dimmer Setup
Aux1 X
Aux2
Sprinklers
Cancel Today
Manual Start
Enable Programs
Disable Programs
Highlight an item
and press SELECT
