System Temperature; Set Degrees (Celsius Or Fahrenheit); Temp Calibrate - Jandy Pro Series AquaLink RS OneTouch Control Systems Owner's Manual

AquaLink RS OneTouch™ | Owner's Manual
®
Seasonal Adjust Values
Program Default Adjustable Range
Filtration 1 hr
Cleaner 1 hr
*
† AquaPure 15%
®
Sprinklers 5 min
Fill Line 5 min
‡
*Will only display if DIP Switch S1-1 is on
Will only display if a chlorine generator is attached to the system
†
Will only display if an AUX has been assigned the FILL LINE label
‡

3.5 SYSTEM TEMPERATURE

The following functions provide
controls for the setup, display and
maintenance of system temperature,

3.5.1 SET DEGREES (CELSIUS OR FAHRENHEIT)

MENU/HELP
SYSTEM SETUP
Select to set system temperature to
display in degrees Celsius (°C) or
Fahrenheit (°F).
NOTE: Changing from ºF. to ºC
requires reentry of the temperature
settings in SET TEMP under MAIN
MENU. See "4.4.2 Set Temp".

3.5.2 TEMP CALIBRATE

MENU/HELP
SYSTEM SETUP
Select to adjust the temperature
displayed on the AquaLink RS
system.
• Temperature can only be adjusted
by 4° F up or down, and should
be made for accuracy only, not to
override the standard maximum of
104º F.
NOTE: If system temperature is
off by more than 4°F, contact your
local service representative.
.5 hr 1.5 hrs, 2 hrs
.5 hr 1.5 hrs, 2 hrs
10%, 15%, 20%
2-10 min
N/A
ENGLISH
PGM 1 of 1
On
Off
All Day
Add
Delete
Change
along with temperature sensitive
controls for the automation of
equipment operation.
System Setup
OneTouch
Label Aux
Freeze Protect
Air Temp
Degrees C/F
Temp Calibrate
In Floor Clean
Solar Priority
More
System Setup
OneTouch
Label Aux
Freeze Protect
Air Temp
Degrees C/F
Temp Calibrate
In Floor Clean
Solar Priority
More
Page 13
Filter Pump
8:00 AM
4:00 PM
Program
Program
Program
Degrees C/F
Fahrenheit
Celsius
Choose setting
and press SELECT
Temp Calibrate
80°F
Water Temp
Use ARROW KEYS
to set value.
press SELECT
when finished.
