AquaLink RS OneTouch™ | Owner's Manual
®

4.3.3 VARIABLE SPEED PUMP

4.3.3.(A) VARIABLE SPEED PUMP (SETUP)
MENU/HELP
SYSTEM SETUP
Select to set up the variable speed
pump. The following functions
provide controls for selecting the
pump type, and for setting the pump
4.3.3.(B) PUMP MODEL
MENU/HELP
SYSTEM SETUP
Select to control one of four
types of Variable speed pumps:
Jandy ePump™, IntelliFlo
®
IntelliFlo VS, or IntelliPro
4.3.3.(C) PUMP APPLICATION
MENU/HELP
SYSTEM SETUP
Select to set pump application.
Up to 4 variable speed pumps
can be controlled and assigned
a specific application based on
equipment installed (see table
below). The default setting is
NOT INSTALLED. The pump can
also be configured as an AUX and
operate independently of the water
filtration mode.
Variable Speed Pump Application
Combo
FILTRATION
NOT INSTALLED
AUX. PUMP
VAR SPEED PUMP PUMP MODEL
VF,
®
VS .
® 1
VAR SPEED PUMP PUMP APPLICATION
Pool/Spa Only Dual Equipment
FILTRATION
NOT INSTALLED
AUX. PUMP
NOT INSTALLED
ENGLISH
application, speed and speed/flow
limits, custom labels as well as
priming speed and duration.
Vsp settings
Pump model
Pump application
Min-max settings
Speed/labels
Prime
Highlight an
Item and press
SELECT
Pump Application
Pump 1
Pump 2
Pump 3
Pump 4
Highlight an
Item and press
SELECT
POOL PUMP
SPA PUMP
AUX. PUMP
Page 21
Pump model
ePump x
Intelliflo VF
Intelliflo VS
Highlight an
Item and press
SELECT
Pump Application
Pump 1
Filtration
X
Aux. Pump
Not Installed
Highlight an
Item and press
SELECT
