XR480 BEAM
PR-2455
The user manual contains important information about the safe installation and use of a projector. Please read
and follow these instructions carefully and keep the manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com
1/28

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XR480 BEAM and is the answer not in the manual?

Questions and answers

Related Manuals for PR Lighting XR480 BEAM

Summary of Contents for PR Lighting XR480 BEAM

  • Page 1 XR480 BEAM PR-2455 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...
  • Page 2 Any damage caused by improper use will not be assumed by the manufacturer and / or dealer. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty.

  • Page 3: Safety And Warnings

    1. SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Electrical Protective High Warning Goggles Flames Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector.

  • Page 4: Cleaning And Maintenance

    There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety ● cord supplied through the safety cord holes for safety support. Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from ●...

  • Page 5: Troubleshooting

    TROUBLESHOOTING ● PROBLEM ACTION Ø Check the fuse on the power socket. The projector doesn’t switch on Ø Check the lamp. Ø The lamp is on but the projector doesn’t respond Make sure that the fixture’s start address is right Ø...

  • Page 6: Installation

    4. INSTALLATION RIGGING ● Before moving a projector, Please lock Pan and Tilt. Before its operation, please unlock them. It’s forbidden to run a projector with power while it is locked. Take 2 clamps and the safety cord out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to each clamp.

  • Page 7: Dmx Control Connections

    DMX CONTROL CONNECTION: ● DMX OUT DMX IN DMX 512 FUNCTION 3-Pin DATA- DATA+ DMX OUT DMX IN DMX 512 FUNCTION 5-Pin DATA- DATA+ Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each wire having at least a 0.5mm in diameter.

  • Page 8: Alignment/Installation/Replacement Of A Lamp

    ALIGNMENT/INSTALLATION/REPLACEMENT OF A LAMP ● Lock the yoke before fitting/replacing the lamp. Just as Shown by Figure 1, after opening the cover at the rear of the projector by loosening 4 fastfit screws, you can open the head. To adjust the lamp as per Figure 2. Take out the lamp as per the figure 3.

  • Page 9: Setup And Configuration

    5. SETUP AND CONFIGURATION FRONT PANEL OPERATION ● The projector configuration can be set conveniently via push buttons and color touch screen. To browse through or change the projector ’s settings, touch the white area of the touch screen or press OK button for more than ►...

  • Page 10: Master/Slave Mode

    fixture’s DMX output to the third fixture’s DMX input, and so on until all projector are c fixture’s DMX output to the third fixture’s DMX input, and so on until all projector are connected in this way. Eventually connect the onnected in this way.
  • Page 11 Ch.12 Prism1 Rotation Ch.13 Prism2 Ch.14 Prism2 Rotation Ch.15 Frost Ch.16 Focus Ch.17 Pan Ch.18 Tilt Ch.19 Control Function Lamp Control OFF/ ON On By Power On OFF/ ON Lamp Control Control By DMX OFF/ ON Lamp Half Power OFF/ ON XLR Only XLR First Signal Select...
  • Page 12 Settings Tilt DMX Invert Tilt DMX Invert OFF/ ON Pan Tilt Swap OFF/ ON XY Feedback OFF/ ON Note: "Speed Mode" means Note: "Speed Mode" means Pan and Tilt will move from Pan and Tilt will move from Point A to Point B at their Point A to Point B at their respective maximum respective maximum...

  • Page 13: Stand-Alone Mode

    Speed Status Speed Status Lamp Fan Lamp Fan xxx on/off Lamp Fan2 xxx on/off Lamp Fan2 xxx on/off Ceramic Fan xxx on/off Ceramic Fan xxx on/off Fan Status CYM Fan CYM Fan xxx on/off xxx on/off Head Fan Head Fan xxx on/off xxx on/off Head Fan2...
  • Page 14 Change Operation Mode? Change Operation Mode? Static Scene Confirm or Cancel Confirm or Cancel Strobe XXX Strobe XXX Dimmer XXX Dimmer XXX Dimmer Fine XXX Dimmer Fine XXX CYM Macro XXX CYM Macro XXX Cyan XXX Cyan XXX Cyan Fine XXX Cyan Fine XXX Yellow XXX Yellow XXX...
  • Page 15 Pan & Tilt Speed &Time Control Function Reset User Memory? Reset User Memory 1 Confirm or Cancel Reset User Memory? Reset User Memory 2 Init User Memory Confirm or Cancel Reset Static Scene? Reset Static Scene Confirm or Cancel 15/28...
  • Page 16 7. DMX PROTOCOL Short Standard Extended FUNCTION DESCRIPTION mode mode Mode 000-010 Close 011-025 Open Strobe Strobe speed from slow to fast 026-225 Random strobe from slow to fast 226-246 247-255 Open 000-035 Close Dimmer （0-100%） 036-255 Linear dimming 000-255 Dimmer Fine Dimmer in 16 bit White...
  • Page 17 Wheel 038-043 Gobo4/ Dot4 044-049 Gobo5/ Dot5 050-055 Gobo6/ Dot6 056-061 Gobo7/ Ping 0620-67 Gobo8/ Fan 068-073 Gobo9/8 Bars 074-079 Gobo10/ Flower 080-085 Gobo11/ Rectangles 086-091 Gobo12/ Stars 092-097 Gobo13/ Five Dots 098-103 Gobo14/ Eight 104-109 Gobo15/ Quadrangles 110-115 Gobo16/ Steering Wheel 116-121 Gobo17/ 4 paralleled Bars 122-127...
  • Page 18 Reverse Rotation（anti-clockwise From slow 157-185 to Fast） 186-195 Shake of Gobo 1 from slow to fast 196-205 Shake of Gobo 2 from slow to fast 206-215 Shake of Gobo 3 from slow to fast 216-225 Shake of Gobo 4 from slow to fast 226-235 Shake of Gobo 5 from slow to fast 236-245...

  • Page 19: Error Messages

    040-044 Lamp Full Power Reserved 045-089 090-094 Pan & Tilt Speed Mode Pan & Tilt Speed Mode Pan & Tilt Time Mode 095-099 100-129 Reserved Lamp On 130-139 140-149 Pan & Tilt Reset 150-159 Color System Reset 160-169 Gobo Wheels Reset 170-179 Dimmer/Shutter Reset Frost/Focus/Prism Reset...
  • Page 20 9. ERROR MESSAGES The system can detect some errors during the reset, if The system can detect some errors during the reset, if displayed, touch the logo to view the error. The error messages are as follows: Name Type Correction Timeout/magnet Sensor/Encoder Timeout/magnet Sensor/Encoder Check if wiring, positioning parts and motors are normal...

  • Page 21: Technical Data

    8. TECHNICAL DATA INPUT VOLTAGES 100V~240V AC，50/60Hz RATED POWER 650W@220V LAMP SPECIFICATIONS International brand 480W Color Temperature 6900K Manufacturers Rated Lamp Life 1500hours COLORS CMY linear color mixing with macros 1 color wheel: 11colors+1CTO+ Open Rainbow effect with bi-directional and variable speeds Stepping/linear color changing Color 9 Color 10...
  • Page 22 FIXED GOBO WHEEL 1 fixed gobo wheel: 18 gobos +open bi-directionally rotatable, and shakable at variable speeds directionally rotatable, and shakable at variable speeds Dot2 Dot3 Dot4 Dot5 Dot6 Ping （φ1.2mm） （φ2.0mm） （φ3.5mm） （φ4.5mm） （φ6.0mm） （φ8mm） 8 Bars Flower Rectangles Stars Five Dots Eight...
  • Page 23 FROST 1pc frost filter FOCUS DMX linear Focus DIMMER/STROBE 0-100% linearly adjustable/ Double shutter blades, 0.3~25 F.P.S HEAD MOVEMENT Pan 540º, Tilt 270º with auto position correction BEAM ANGLE Beam angle: 3.3° CONTROL International DMX512 Signal, 3 pin and 5 pin interfaces 19channels in short mode, 26channels in standard mode and 29channels in extended mode Self-test mode OTHER FUNCTIONS...
  • Page 24 SIZES LIGHT OUTPUT 24/28...

  • Page 25: Circuit Diagram And Pcb Connections

    9. CIRCUIT DIAGRAM AND PCB CONNECTIONS CIRCUIT DIAGRAM ● 25/28...

  • Page 26: Pcb Connections

    PCB CONNECTIONS ● P/N230060787 1.8-Channel SLAVE1： 8-Channel Slave1 M1-1 Motor 24V Power Input M1-2 Motor M1-3 Motor M1-4 Motor HALL1-6 Magnet Sensor M1-5 Motor HALL1-5 Magnet Sensor M1-6 Motor HALL1-4 Magnet Sensor M1-7 Motor HALL1-3 Magnet Sensor M1-8 Motor HALL1-2 Magnet Sensor Thermal Switch #2 HALL1-1 Magnet Sensor MEMS Sensor...

  • Page 27: Component Order Codes

    10. COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK PAN MOTOR 030040233A 030040233A TILT MOTOR 030040242 DIMMER/STROBE MOTORS CYM MOTOR 030040241 ROTATING GOBO WHEEL MOTOR 030040244 030040073A FIXED GOBO WHEEL MOTOR 030040224A COLOR WHEEL MOTOR GOBO ROTATION MOTOR 030040073A 030040243 FOCUS MOTOR 030040221A FROST MOTOR...
  • Page 28 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320020553 Version: 20171024 (Preliminary）...
