Summary of Contents for PR Lighting XR 1700 FRAMING
- Page 1 XR 1700 FRAMING PR-2887 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD.
- Page 2 Any future technical changes in the user manual won’t be with any further notice. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty.
- Page 3 1. SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. Warning User Electrical Protective Flames High Goggles Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector.
- Page 4 cord supplied through the safety cord holes for safety support. Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from ● power mains. ℃.After stable operation , After running for 5minutes, the temperature of the housing of the projector is ●...
- Page 5 3. APPEARANCE HEAD BASE 4. INSTALLATION RIGGING ● Before moving a projector, Please lock Pan and Tilt. Before its operation, please unlock them. It’s forbidden to run a projector with power while it is locked. WARNING CLAMP TO pass 2 SAFETY CORDS through 4 HOLES for safety HOLES for SAFETY CORDS CONTROL...
- Page 6 The earth wire(yellow/green) must be connected to the ground. And electrical connection must be in ● accordance with the standards concerned. If any questions about the electrical installation, do not continue but consult a qualified electrician. ● DMX CONTROL CONNECTION: ●...
- Page 7 DMX TERMINATOR CONNECTION Connect a 120 (OHM) resistor across pins 2 and 3 in an XLR plug and insert into the DMX out socket on the last unit in the chain. PIN 2 PIN 3 ALIGNMENT/INSTALLATION/REPLACEMENT OF A LAMP ● Before installation/replacement/alignment of a lamp, disconnect the unit from the power and let it cool first.
- Page 8 GOBO REPLACEMENT ● FRAMING MODULE ROTATING GOBO WHEEL 2 EFFECT WHEEL ROTATING GOBO WHEEL 1 COLOUR WHEEL Lock the tilt and loosen the 6 fast-fit screws on the upper cover ,After removing the cover, you will see the structures as the figure below.
- Page 9 Or touch the option needed for change. Shortcut keys: After the Function Menu is entered into, there are all options for the functions on the top of the screen. On the ←,→ right there are 4 shortcut keys like Lamp Control and English/Chinese. DMX START ADDRESS ●...
-
Page 10: Operation Menu
SLAVE SLAVE MASTER DMX IN DMX IN DMX IN DMX OUT DMX OUT DMX TERMINATOR FIRMWARE UPGRADE VIA USB INTERFACE ● Copy the .PRS file for upgrading to U disk and plug it into USB interface. The upgrading file name or its file folder can be seen via the USB firmware upgrading interface under menu SERVICE. - Page 11 Normal time out Loss of DMX Hold Last Value Off After Delay Display Mode On Always Invert OFF Display Config Display Invert Invert ON Invert Auto English Language Setting Chinese Input Password 123 Touch Calibration Celsius Degree Temperature Unit Fahrenheit Degree Un-Link Wireless Really Un-Link? Defaults...
- Page 12 Boot =XXX System= XXX Pan and Tilt Boot =XXX Electronic SN= Electronic SN ************ RDM Device Label RDM Device Label ANSI E1.20 RDM Version X.X Fan Status Strobe XXX Manual Effect Control Dimmer XXX Service … USB Update Software Factory Test Change Operation Mode? DMX Mode Preset Memory...
- Page 13 Fine dimmer CYM Macro The following functions can be used after CMY,CTO, Color Wheel1 and Color Wheel2 channels are disabled No Function Colour Macro 1 Colour Macro 2 Colour Macro 3 Colour Macro 4 Colour Macro 5 Colour Macro 6 Colour Macro 7 Colour Macro 8 Colour Macro 9...
- Page 14 LEE 88 (Lime Green) LEE 90 (Dark Yellow Green) LEE 100 (Spring Yellow) LEE 101 (Yellow) LEE 102 (Light Amber) LEE 103 (Straw) Lee 104 (Deep Amber) LEE 105 (Orange) LEE 106 (Primary Red) LEE 111 (Dark Pink) LEE 115 (Peacock Blue) LEE 116 (Medium Blue-Green) LEE 117 (Steel Blue) LEE 118 (Light Blue)
- Page 15 LEE 202 (Half C.T. Blue) LEE 203 (Quarter C.T. Blue) LEE 204 (Full C.T. Orange) LEE 205 (Half C.T. Orange) LEE 206 (Quarter C.T. Orange) LEE 247 (LEE Minus Green) LEE 248 (Half Minus Green) LEE 281 (Three Quarter C.T. Blue) LEE 285 (Three Quarter C.T.
- Page 16 Colour 4(Green)/colour 5(Pink) Colour 5(Pink) Colour 5（Pink））/colour 6（Orange） Colour 6(Orange) Colour 6(Orange)/ Colour 7(UV) Colour 7(UV) Colour 7(UV)/white Rainbow rotation speed from slow to fast Rainbow reverse rotation speed from slow to fast Colour Wheel 1 Fine Colour Continual positioning in 16 Bit precision Iris Linear Iris from small to big 0-100% Iris in 16 bit...
- Page 17 Gobo2 shake from slow to fast Gobo3 shake from slow to fast Gobo4 shake from slow to fast Gobo5 shake from slow to fast Gobo6 shake from slow to fast Rotating gobo wheel 1 rotation Indexing 0-360° Stop Clockwise rotation from slow to fast Stop Anti-clockwise rotation from slow to fast Rotating gobo wheel 1 rotation in 16 bit...
- Page 18 Framing blade 1 right fine adjustment Framing blade 2 left Framing blade2 left linearly closing from big to small Framing blade 2 left in 16 bit Framing blade 2 left fine adjustment Framing blade 2 right Framing blade 2 right linearly closing from big to small Framing blade 2 right in 16 bit Framing blade 2 right fine adjustment Framing blade 3 left...
- Page 19 Prism Prism2 rotation Prism index Stop rotating Rotation speed from slow to fast Stop rotating Reverse rotation speed from slow to fast Dual Effect Wheel No effect wheel Proportional indexing Shake from open to full position with speed from slow to fast Shake from open to half position with speed from slow to fast Shake.
- Page 20 Zoom Linearly zooming Zoom Fine Zoom in 16 Bit precision Pan movement Pan Fine Pan movement in 16 bit precision Tilt Tilt movement Tilt fine Tilt movement 16 bit precision Pan/Tilt speed fast Speed Mode Pan &Tilt speed from fast to slow Power/Special functions No function: Reserved...
-
Page 21: Error Messages
2. Fan error can cause lamp-off. 3. "Speed Mode" means Pan and Tilt will move from Point A to Point B at their respective maximum speeds."Time Mode" 3. "Speed Mode" means Pan and Tilt will move from Point A to Point B at their respective maximum speeds."Time Mode" 3. -
Page 22: Technical Data
Effect Wheel Timeout Check if wiring, positioning parts and motors are normal Effect Wheel Timeout Check if wiring, positioning parts and motors are normal Rotation Lamp Fan1 Error Check if fan and its wiring are normal Check if fan and its wiring are normal Lamp Fan2 Error Head Fan 1... - Page 23 1Color wheels: 7colors+ Open, half-color effect, bi-directional rainbow effect with variable speeds, Stepping/linear color changing Color Wheel Code No. Colors Wave Length λ=620±5nm 090070041A λ=510/545±5nm 090070044A Yellow λ=500±5nm 090070043A Blue λ=540±5nm 090070042A Green λ=490/585±5nm 090070045A Pink λ=600±5nm 090070046A Orange λ=460/690±5nm 090070047A UV light 0-100% Linear CTO system...
- Page 24 PRISM 1pc 6-facet circular prism and 1pc 6 facet linear prism, indexing, bi-directional rotation with variable speeds FROST 2Pc frost filters(1 light frost filter and 1 heavy frost filter)linear adjustment and both can overlap EFFECT WHEEL Dual effect wheels, Each has independent and bi-directional rotation with variable speeds FOCUS DMX linear Focus DIMMER...
-
Page 25: Operation Temperature
High temperature ABS, IP20 WEIGHT 52Kg OPERATION TEMPERATURE Maximum ambient temperature: 40°C RIGGING Placed on the floor, hung upside down SIZES LIGHT OUTPUT 55°（ lux） 2535 5° （lux） 180092 45023 20010 11256 7204 5003 55° 5° DISTANCE （ m） 0m 5°... - Page 26 A C B D A C B D A C B D A C B D A C B D A C B D A C B D G B A Head Temperature Switch A C B D On/Off L-STATUS...
-
Page 27: Component Order Codes
12. COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK POWER SWITCH 230020689 PR-MP300 POWER FILTER 193020008 20A 115/250VAC THERMAL SWITCH 190010150 250V-16A ELECTRONIC BALLAST 040070140 ELECTRONIC BALLAST IGNITER 040090066 IGNITER LAMP 100050085 LOK-IT! HTI 1700/PS PAN BELT 290151205 558-3M-11 TILT BELT 885-3M-12 290151207 PAN MOTOR... - Page 28 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320020574...
