PR Lighting XR 380 Beam User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XR 380 Beam
PR-2345A
The user manual contains important information about the safe installation and use of a projector. Please read and
follow these instructions carefully and keep the manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XR 380 Beam and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PR Lighting XR 380 Beam

Summary of Contents for PR Lighting XR 380 Beam

  • Page 1 XR 380 Beam PR-2345A The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD.

  • Page 2: Table Of Contents

    Any future technical change in the user manual won’t be with any notice. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty...

  • Page 3: Safety And Warnings

    1. SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. Warning User Electrical Goggles Protective Flames High Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector.

  • Page 4: Instructions

    Any electrical connection must be carried out by a qualified person . ● Before installation, please confirm the voltage supplied matches what is required for the projector ● Each projector must be properly earthed and installed as per related electrical standards. ●...

  • Page 5: Appearance

    ●LUBRICATION To ensure smooth movement of gobos and zoom and focus lens, it’s advised rotators’ bearings and 2 sliding bars for zoom and focus lens be lubricated every 2 months. High quality and high temperature lubricant/grease is advised.. ●TROUBLESHOOTING PROBLEM ACTION ...
  • Page 6 Use the spanner supplied with a projector to help installation. WARNING: The projector MUST be lifted or carried by the HANDLES instead of clamps. ● .For safety the safety cord should afford 10 times the Projector’s weight. ●...
  • Page 7 It must use secondary safety accessory like appropriate net. The structures of the secondary accessory must ensure that while malfunction happens, the installed parts won’t fall to the ground. While rigging, mounting or maintaining, the projector mustn’t be placed in the areas listed hereinafter: the bridge, high work areas or other dangerous areas.
  • Page 8 POWER IN POWER OUT DMX IN DMX OUT POWER IN POWER OUT DMX IN DMX OUT POWER IN POWER OUT DMX IN DMX OUT FUSE 250V 8A FUSE 250V 8A FUSE 250V 8A DMX512 OUTPUT INPUT OUTPUT INPUT terminator ●DMX TERMINATOR In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator.

  • Page 9: Setup And Configuration

    5. SETUP AND CONFIGURATION ●FRONT PANEL OPERATION To browse through or view a projector’s function settings, push any key to activate the screen after power-on.. After screen unlocked, push both key and to enter into menus. Each main menu has its sub-menus with different special functions, for details please see the 5 point hereinafter OPERATION MENU.

  • Page 10: Operationmenu

    MASTER SLAVE SLAVE POWER IN POWER OUT DMX IN DMX OUT POWER IN POWER OUT DMX IN DMX OUT POWER IN POWER OUT DMX IN DMX OUT FUSE 250V 8A FUSE 250V 8A FUSE 250V 8A OUTPUT INPUT OUTPUT INPUT terminator 6.
  • Page 11 display（Open or Close） 2）Push UP or DOWN key to select either of the options.3） Push ENTER key to save the selected. PUSH ESCAPE key to cancel the setting. Channel Push both UP and DOWN keys to enter into the menu， （Hidden ）...

  • Page 12: Dmx Protocol

    key to cancel the setting. Select“Language”options Chinese 1）Push UP or DOWN key to select either of the options. Languages 2）Push ENTER key to save the selected. PUSH ESCAPE English key to cancel the setting. Select“Display”options Normal 1） Push ENTER key and the way the screen displayed will Display be shown 2）Push UP or DOWN key to select either of the options.
  • Page 13 Strobe Close 4-103 Strobe: Slow->Fast 104-107 Open 108-207 Pulse strobe: Slow->Fast 208-212 Open 213-225 Strobe at random: slow speed 226-238 Strobe at random: medium speed 239-251 Strobe at random: fast speed 252-255 Open Dimmer 0-255 0-100% Colors Open Open+ Color1 9-12 Color1 13-17...
  • Page 14 Fixed gobo wheel Open GOBO1 8-11 GOBO2 GOBO3 12-15 GOBO4 16-19 GOBO5 20-23 GOBO6 24-27 GOBO7 28-31 GOBO8 32-35 GOBO9 36-39 GOBO10 40-43 GOBO11 44-47 GOBO12 48-51 GOBO13 52-55 GOBO14 56-59 GOBO15 60-63 64-67 GOBO16 GOBO17 68-71 72-78 GOBO1 SHAKE: Slow->Fast GOBO2 SHAKE: Slow->Fast 79-85 GOBO3 SHAKE: Slow->Fast...

  • Page 15: Error Message

    64-255 Prism 2 in Prism rotation 0-127 0-360° 128-190 Clockwise rotation: Fast->Slow 191-192 Stop 192-255 Anti-clockwise rotation: slow->fast Frost 0-255 0-100% Focus 0-255 0-100% Reset 0-25 26-76 Head reset 77-127 Pan & Tilt reset 128-255 Total reset Lamp control 0-25 26-100 Lamp off 101-255...
  • Page 16 COLORS 1color wheel: 14colors+ Open FIXED GOBO WHEEL 1 fixed gobo wheel: 17gobos+open, gobo diameter=6mm, its thickness=0.8mm PRISM/FROST 1 8-facet prism and 1 16-facet prism, bi-directional rotation from slow to fast , both can be overlapped FOCUS DMX linear focus DIMMER /STROBE Strobe at variable speeds(15 F.P.S at maximum) 0-100% linear dimmer...
  • Page 17 Pan 540º , Tilt 270º with 16 bit control BEAM ANGLE 0° ～ 2° CONTROL International standard DMX 512 protocol, 5-pin interface 14channels in short mode and 16channels in standard mode HOUSING High temperature and anti-UV ABS and aluminum , IP20 NET WEIGHT 17Kg OPERATION TEMPERATURE...

  • Page 18: Circuitdiagram

    10. CIRCUITDIAGRAM...

  • Page 19: Component Order Codes

    11. COMPONENT ORDER CODES Name Code No. Remarks Pan Motor 50300-00096 Tilt Motor 50300-00097 50502-00157 50502-00158 50502-00159 50502-00160 50502-00161 50502-00162 14colors, each code no. stands for 50502-00163 Color wheel one color, colors start from red and 50502-00164 so on 50502-00165 50502-00166 50502-00167 50502-00168...

  • Page 20: Appendix

    APPENDIX: SOME ITEMS REQUIRING ATTENTION AS FOR THE USE OF DISCHARGE LAMP For the effective extension of the lifespan of discharge lamp, some factors impacting its lifespan are specially listed below, based on manufacturing technology and working mechanism of discharge lamps., physical attributions of the lamps including lamp striking theory( ignited by focused high voltage---highly pressurized air broken down and burning---lamp on at high temperature with thermal protection--- stable running) and lamp off theory( lamp off power ---lamp off at high temperature and thermal protection-highly pressurized air vaporizing evenly----completion of lamp...
  • Page 22 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320021388...
