Carrier CDII-184R1-0CTR4 Installation & Operation Manual page 84

# PART NO.
1 3ASAG-20-002
2 3BAE-01-006
3 3BAE-01-606
4 3ASAG-21-220
5 3ASAG-20-230
6 3ASAG-20-106
7 3ASAG-30-242
8 2AL0-60-042
9 3ASAG-20-022
10 3ASAG-20-012
11 3DAE-10-075
12 3ASAG-20-111
13 2AX5-00-137
14 3ASAG-20-149
15 3ASAG-20-101
16 3ASAG-00-094
16(a) 3ASAG-00-161
17 3ASAG-30-021
17(a) -
17(b) -
18 3ASAG-00-090
19 3ASAG-10-090
20 3ASAG-30-300
20(a) -
21 3BP5-50-246
22 3ASAG-30-159
23 3ASAG-30-259
24 2AL0-00-178
25 3ASAG-20-078
26 3ASAG-30-221
27 -
28 -
29 -
30 -
31 -
32 -
33 -
34
35
36
PART NAME
BASE PAN ASSY.
BASE CHANNEL SUB ASSY.(L)
BASE CHANNEL SUB ASSY.(R)
SIDE PANEL LEFT
SIDE PANEL RIGHT
DRAIN PAN ASSY.
CLAMP FILTER DRIER
FILTER DRIER
COIL BRACKET LEFT
COIL BRACKET RIGHT
FRONT TOP PANEL
ASSY. TOP PANEL
GROMMET
FILTER ASSY.
SUB ASSY. FAN DECK
BLOWER (10"x10")
HOUSING (10"x10")
ASSY. COIL EVAP.
EXV CAM
EXV MOTOR
MOTOR DOUBLE SHAFT
MOTOR SINGLE SHAFT
CONTROL BOX ASSY. (22HP)
FCU PCB (22HP)
SIDE PLATE
STICKER MASTER (CKT-1)
STICKER SLAVE (CKT-1)
CARRIER STICKER
TOP SUPPORT BKT.
PANEL REMOVE
TOUCH BASED REMOTE CONTROL (DT07)
2 CORE WIRE CORDED REMOTE CONTROL (Optional)
CORDLESS REMOTE CONTROL (Optional)
FCU RETURN AIR (AMBIENT) SENSOR
FCU COIL_1 IN (IN LET) TEMPERATURE SENSOR
FCU COIL_1 MIDDLE (MID LET) TEMPERATURE SENSOR
FCU COIL_1 OUT (OUT LET) TEMPERATURE SENSOR
FCU Coil_2 IN
(IN LET) TEMPERATURE SENSOR
FCU Coil_2
MIDDLE (MID LET) TEMPERATURE SENSOR
FCU Coil_2
OUT (OUT LET) TEMPERATURE SENSOR
84
QTY SAP
1 1031532
1 1006474
1 1006425
1 1031530
1 1031531
1 1031536
2 1031962
2 1018258
1 1031534
1 1031533
1 1006452
1 1031535
2 1004451
1 1031555
1 1031537
3 1031968
3 1031971
1 1513074
1 1022536
1 1022537
1 1031972
1 1031973
1 1513072
1 1031925
2 1022530
1 1031949
1 1031951
1 1004406
2 1031963
1 1031961
1 1029778
1 1029777
1 1029780
1 1029787
1 1029784
1 1029785
1 1029786
1
1031988
1
1031989
1
1031990
