PACKAGE CONTENTS
UNIT SIZE
Short Chassis 44 in. Tall
Tall Chassis 52 in. Tall
SAFETY CONSIDERATIONS
Installation and servicing of air-conditioning equipment can be
hazardous due to system pressure and electrical components. Only
trained and qualified service personnel should install, repair, or
service air-conditioning equipment.
Untrained personnel can perform basic maintenance functions of
cleaning coils and filters and replacing filters. All other operations
should be performed by trained service personnel. When working
on air-conditioning equipment, observe precautions in the
literature, tags and labels attached to the unit, and other safety
precautions that may apply.
Follow all safety codes. Wear safety glasses and work gloves. Use
quenching cloth for unbrazing operations. Have fire extinguisher
available for all brazing operations.
It is important to recognize safety information. This is the safety-
alert symbol
. When you see this symbol on the unit and in
instructions or manuals, be alert to the potential for personal
injury.
Understand the signal words DANGER, WARNING, CAUTION,
and NOTE. These words are used with the safety-alert symbol.
DANGER identifies the most serious hazards which will result in
severe personal injury or death. WARNING signifies hazards
which could result in personal injury or death. CAUTION is used
to identify unsafe practices, which may result in minor personal
injury or product and property damage. NOTE is used to highlight
suggestions which will result in enhanced installation, reliability,
or operation.
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53480312-01
Installation Instructions
Page
PART NUMBER
CRECOMZR054B00
CRECOMZR055B00
Printed in U.S.A.
Form IIK-CRECOMZR54-04
Vertical and Horizontal
Economi$er
Medium Rooftop Units
IMPORTANT: Read these instructions completely before
attempting to install the accessory EconoMi$er2 system.
PACKAGE CONTENTS
UNIT NO.
QTY
1
Damper Assembly
1
Upper End Economizer Panel
Bottom Panel with Relief Damper
1
(for vertical only)
1
Bottom Panel #2 (for horizontal only)
Side Replacement Panel (for horizontal
1
only)
3
Filter Supports
3
Central Retainer
CRECOMZR054B00
2
Side Retainer
1
Hood Top
1
Left Hood Side
1
Right Hood Side
2
Top Diverters
3
Deflector
4
Outside Air Filter Screens
1
Hardware bag with screw, etc.
1
Damper Assembly
1
Upper End Economizer Panel
Bottom Panel with Relief Damper (for
1
vertical only)
1
Bottom Panel #2 (for horizontal only)
Side Replacement Panel (for horizontal
1
only)
3
Filter Supports
3
Central Retainer
CRECOMZR055B00
2
Side Retainer
1
Hood Top
1
Left Hood Side
1
Right Hood Side
2
Top Diverters
3
Deflector
4
Outside Air Filter Screens
1
Hardware bag with screw, etc.
CAUTION
ELECTRICAL SHOCK HAZARD
Failure to follow this warning could result in personal injury
and/ or death.
Disconnect power supply and install lockout tag before
attempting to install accessory.
Pg 1
2 Accessory
®
15 to 27.5 Tons
CONTENTS
7-21 Replaces: IIK-CRECOMZR54-03
