1. Foreword

CNC49 series cnc controllert developed by Adtech (Shenzhen) CNC Technology Co., Ltd. for milling
machines and machining centers, CNC4940 is four axis motion controller and CNC4960 is six axis motion
controller.
Instructions and reading convention of the Manual
Before using this CNC system, please read this Manual carefully to operate properly.
Terminology note and reading convention in this Manual:
CNC4940 and CNC4960 are the controller with different axis and same hardware.
―CNC system‖, ―NC controller‖ and ―CNC49XX‖ mentioned in this Manual all refer to CNC4940/4960
The articles marked with ―Caution‖ prompt users to pay special attention for operation or setting, or else this
operation may fail or certain action can't be performed.

2. System technical characteristics

2.1 System technical parameters

Function
Control axis
Input instruction
Feeding
ADTECH 4 series CNC System (maintainance Manual)
Name
Control axis
Simultaneous control axes
Minimum setting unit
Minimum moving unit
Maximum instruction value
Fast feeding speed
Per minute
Feeding speed range
Per rotation
Automatic acceleration/deceleration
Specification
4 axes (CNC4940 series)
6 axes (CNC4920 series)
4 axis linear interpolation (CNC4940
series)
6 axis linear interpolation (CNC4960
series)
0.001mm
0.001mm
±9999.999 mm
X axis, Y axis, Z axis, A axis: B axis, C
axis 9999 mm/min (maximum)
1~9999mm/min
1~500rpm
Yes
