Spindle stop accurately
Since tool installed on the spindle, cutting torque transmited can't only by bole-hole's friction, so there
are one bolt at ahead of the spindle, when tool installed to spindle, the keyway of tool head must match with
the bolt of spindle, and then can finish tool change, so spindle require stopping accurately at a fix angle, this is
the purpose of spindle stop accurately
M89 P8 L1
(20)
M89 P13 L1
(21)
G04 X#407
(22)
M89 P13 L0
(23)
M88 P4 L0 (spindle stop accurately) (wait for spindle stop accurately position)
(24)
This code is corresponding to the flow chart ―spindle accuracy stop‖ and make sure the spindle stop accurately.
X、Y axis position to tool changing point
(25)G01 X[#401] Y[#402] F#406
Above program is for machine move to X and Y axis tool changing point , ready for tools back to tool
magazine, this is corresponding to work flow chart ―Spindle at the point of X/Y axis tool change‖
(26)IF[[#201]!=0]
(27){
(28)G01 Z[#403] F#405
(29)M89 P11 L1
M88 P6 L0
(30)
M89 P12 L1
(31)
G04 P300
(32)
G01 Z[#403+2.5] F1000
(33)
tool )
M88 P9 L0
(34)
(35)G01 Z[#403+#404] F#405
(36)}
Above program is simple and clear, for judging the return tool number is 0 or not , Z axis position to tool
changing point , and then push out tool disc, next step is checking and waiting for disk air cylinder back input
signal, when get this signal means handle on the spindle was block in tool disc already, and then output spindle
air cylinder push signal to loose tool handle, G04 P300 delay is make sure that there is
the tool, ―G01 Z[#403+2.5] F1000‖, this code is add base on customer's tool magazine, not necessary for all
tool magazine. After getting the spindle air cylinder push signal
tool changing.
choose tool nearby
ADTECH 4 series CNC System (maintainance Manual)
.
start spindle stop accurately
(blow)
(blow delay)
(close blow)
(judge if current tool no. is o or not)
(if the value is not 0, then execute next codes 码)
(machine move to Z axis tool chaning point
(air cylinder push out)
(wait for disk air cylinder back input—sensor signal)
(spindle air cylinder push out)
(delay 300 millisecond)
(Z axis rise up 2.5+#403mm to prevent withhold tool disc when loose
(wait for spindle cut loosen input-sensor signal)
(Z axis rise up to safe position)
spindle blow use for blow
off cooling liquid or piece
enough time to loose
, Z axis back to safe height, ready for next
