Open Collector Output - optris CS Operator's Manual

-
34
The sensor is offering two ways of digital communication:
• bidirectional communication (sending and receiving data)
• unidirectional communication (burst mode – the sensor is sending data only)
Figure 21: Digital communication
3.2.2

Open collector output

In case of long lines there is a drop voltage at the ground wire and the mV-output is distorted.
Because of that the brown wire can be used as ground supply and the t/c- wire (type K) as
measuring ground.
