Technical Data
Input (IN/ OUT/ green)
Output (OUT/ yellow)
Temperature range
Output voltage
Thermocouple output
Vcc adjust
Signal processing
Calibration
Failsafe
For a usage of the CS for online maintenance applications (in electrical cabinets e.g.) the following
recommend settings are already included in the factory default setting (but not active):
OUT
1.800.561.8187
inactive
mV output
0...350 °C
0...3.5 V
Inactive
inactive
Hold mode: off
Gain 1.000/ Offset 0.0
Inactive
At 3-state output the following settings are default:
Pre-alarm difference:
2 °C
No alarm level:
8 V
Pre-alarm level:
5 V
Alarm level:
0 V
Service voltage:
10 V
www.
information@itm.com
.com
-
11
